Intraply Shearing Characterization of Thermoplastic Composite Materials in Thermoforming Processes

Abstract:

The Continuous Fibre Reinforcements and Thermoplastic resin (CFRTP) are widely employed in the prepreg processes. Currently, the most used thermoplastic resins in aeronautics are PPS (polyphenylene sulfide) and PEEK (Polyetheretherketone). They present many advantages on their mechanical properties. However, these mechanical properties depend strongly upon the thermoforming conditions, especially the intraply shearing. In order to improve and complete the understanding about the in-plane shear behavior of thermoplastic composite materials in their forming processes, the thermo-mechanical analysis of PPS/carbon and PEEK/carbon commingled fabrics at different forming temperatures are performed by using the bias-extension tests. The experimental data leads to significant difference on the in-plane shear behavior under different temperature, as well as the wrinkles can be noted in certain thermoforming conditions. Therefore, in order to predict the feasible forming conditions and optimize the important forming parameters of the thermoplastic composites, the in-plan shear behaviors in function of temperature will be integrated into our numerical model to carry out the numerical simulations of thermoforming processes.

• Periodical: Key Engineering Materials (Volumes 504-506)
• Pages: 243-248
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.504-506.243
• Online since: February 2012
• Authors: Peng Wang, Nahiene Hamila, Philippe Boisse
• Keywords: Bias Extension Test, In-Plane Shear, Numerical Simulation, Thermoforming, Thermoplastic Composite

References

[1] C.D. Rudd, A.C. Long. Liquid Molding Technologies. Cambridge: Woodhead Pub. Lim., 1997.

[2] P. De Luca, A.K. Pickett. Numerical and experimental investigation of some press forming parameters of two fibre reinforced thermoplastics: APC2-AS4 and PEI-CETEX. Composites Part A. 29 (1998) 101-110.

DOI: 10.1016/s1359-835x(97)00060-2

[3] S.W. Hsiao, N. Kikuchi. Numerical analysis and optimal design of composite thermoforming process. Comp. Meth Appl Mech Engrg. 177 (1999) 1-34.

[4] P. Boisse, N. Hamila, E. Vidal-Sallé, F. Dumont. Simulation of wrinkling during textile composite reinforcement forming. Influence of tensile, in-plane shear and bending stiffnesses. Composites Science and Technology. 71 (2011) 683-692.

DOI: 10.1016/j.compscitech.2011.01.011

[5] N. Hamila, P. Boisse, F. Sabourin, M. Brunet. A semi-discrete shell finite element for textile composite reinforcement forming simulation. International journal for numerical methods in engineering. 79 (2009) 1443-1466.

DOI: 10.1002/nme.2625

[6] K. Potter. Bias extension measurements on cross-plied unidirectional prepreg. Composites Part A. 33 (2002) 63-73.

DOI: 10.1016/s1359-835x(01)00057-4

[7] G. Lebrun, M.N. Bureau, J. Denault. Evaluation of bias-extension and picture-frame test methods for the measurement of intraply shear properties of PP/glass commingled fabrics. Compos Struct. 61 (2003) 341-52.

DOI: 10.1016/s0263-8223(03)00057-6

[8] P. Harrison, M.J. Clifford, A.C. Long. Shear characterisation of viscous woven textile composites: a comparison between picture frame and bias extension experiments. Compos Sci Tech. 64 (2004) 1453-1465.

DOI: 10.1016/j.compscitech.2003.10.015

[9] G.B. McGuinness, C.M.O. Bradaigh. Development of rheological models for forming flows and picture-frame shear testing of fabric reinforced thermoplastic. Journal of Non-Newtonian Fluid Mechanics.73 (1997) 1-28.

DOI: 10.1016/s0377-0257(97)00040-2

[10] D. Jauffrès, C.D. Morris, J.A. Sherwood, J. Chen. Simulation of the thermostamping of woven composites: determination of the tensile and in-plane shearing behaviors. Int J Mater Form. 2 (suppl 1) (2009) 161-164.

DOI: 10.1007/s12289-009-0590-x

[11] A.S. Milani, J.A. Nemes, R.C. Abeyaratne, G.A. Holzapfel. A method for the approximation of non-uniform fiber misalignment in textile composites using picture frame test. Composites Part A. 38 (2007) 1493-1501.

DOI: 10.1016/j.compositesa.2007.01.008

[12] J. Cao, R. Akkerman, P. Boisse, J. Chen et al. Characterization of Mechanical Behavior of Woven Fabrics: Experimental Methods and Benchmark Results. Composites Part A. 39 (2008) 1037-1053.

[13] R.H.W. ten Thije, R. Akkerman. A multi-layer triangular membrane finite element for the forming simulation of laminated composites. Composites Part A, Vol.40, pp.739-753, 2009.

DOI: 10.1016/j.compositesa.2009.03.004
