Synthesis of Laser Beam Rapidly Solidified Novel Surfaces on D2 Tool Steel

Abstract:

Surface layer of D2 tool steel was subjected to laser surface melting using continuous wave 2.5kW CO₂ laser in point source melting mode. The processing parameters were varied to achieve a uniform depth of around 2 mm. Microstructural study revealed epitaxial growth of fine dendritic structure with secondary dendrite arm spacing in the range of 20-25 µm. The phases in the parent annealed sample were BCC ferrite and chromium rich M₇C₃ carbide. The major phase after laser treatment was austenite and M₇C₃. The average hardness of annealed sample was 195 HV which increased to 410 HV after laser melting. Corrosion studies in 2% HCl solution exhibited a drastic improvement in corrosion resistance in laser treated samples. Improvement in properties is attributed to the refinement and uniformity of microstructure in the rapidly solidified surface. The case of a moving heat source was subjected to computer aided simulation to predict the melt depth at different processing conditions in point source melting mode. The calculated depths using the model, in ABAQUS software was found in good agreement with the experimental data.

• Periodical: Key Engineering Materials (Volumes 510-511)
• Pages: 493-499
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.510-511.493
• Online since: May 2012
• Authors: B.A. Ahmed, K.F. Rizwan, Jafar A. Minhas, Syed Waheed-ul-Haq, M. Shahid
• Keywords: CO₂ Laser, D2 Tool Steel, Rapid Solidification, Refined Microstructure

References

[1] Y. Sun, S. Hanaki, H. Uchida, H. Sunada and N. Tsujii, (2003) Rapid effect of hot work tool steel by laser-melting process, Journal. Mater. Sci. Technol. 19, 91-93.

DOI: 10.2355/isijinternational.43.127

[2] F. Abe, K. Osakada, M. Shiomi, K. Uematsu and M. Matsumoto (2001) The manufacturing of hard tools from metallic powders by selective laser melting, Journal of Materials Processing Technology, 111, 210-213.

DOI: 10.1016/s0924-0136(01)00522-2

[3] J.W. Xie, P. Fox, W. O'Neill, C.J. Sutcliffe (2005) Effect of direct laser re-melting processing parameters and scanning strategies on the densification of tool steels, Journal of Materials Processing Technology, 170, 516-523.

DOI: 10.1016/j.jmatprotec.2005.05.055

[4] T H C Childs, C Hauser, and M Badrossamay (2007) Further studies in selective laser melting of stainless and tool steel powders, International Journal of Machine Tools and Manufacture, 47, 779-784.

DOI: 10.1016/j.ijmachtools.2006.09.013

[5] K.A. Chiang, Y.C. Chen (2005) Laser surface hardening of H13 steel in the melt case, Materials Letters, 59, 1919-(1923).

DOI: 10.1016/j.matlet.2005.02.026

[6] R. Colaco, R. Vilar (2005) On the influence of retained austenite in the abrasive wear behavior of a laser surface melted tool steel, Wear, 258, 225-231.

DOI: 10.1016/j.wear.2004.09.029

[7] J. Kusinski, A. Cias, T.M. Pieczonka, A.B. Smith, A Rakowska (1997) Wear properties of T15 PM HSS made indexable inserts after laser surface melting, Journal of Materials Processing Technology, 64, 239-246.

DOI: 10.1016/s0924-0136(96)02573-3

[8] Y. Sun, S. Hanaki, H. Uchida, H. Sunada and N. Tsujii (2004) Fatigue behavior and fractography of laser-processed hot work tool steel', Vacuum, 13, 655-660.

DOI: 10.1016/j.vacuum.2003.12.161

[9] C.T. Kwok, K.H. Lo, W.K. Chan, F.T. Cheng, H.C. Man. (2003) Effect of processing conditions on the corrosion performance of laser surface-melted AISI 440C martensitic stainless steel, Surface and Coatings Technology, 166, 221-230.

DOI: 10.1016/s0257-8972(02)00782-x

[10] C.T. Kwok, K.I. Leong, F.T. Cheng, H.C. Man (2003) Microstructural and corrosion characteristics of laser surface-melted plastics mold steels, Materials Science and Engineering A, 357, 94-103.

DOI: 10.1016/s0921-5093(03)00228-4

[11] A. Conde, R. Colaço, R. Vilar and J. de Damborenea (2000) Corrosion behaviour of steels after laser surface melting, Materials & Design, 21, 441-445.

DOI: 10.1016/s0261-3069(00)00037-6

[12] Roland W. Ohse, Laser application in high temperature materials, Pure &Appl. Chem., Vol. 60, No. 3, pp.309-322, (1988).

[13] P.R. Strutt, Mat. Sci. Engg. , 44, (1980).

[14] Information on http: /cartech. ides. com/datasheet. aspx?i=103&e=263&c=techart, June 20, (2011).

[15] P.R. Strutt, J. Lemay and A. Tauqir, New Phenomenon in Electron Beam Glazing, Rapidly Solidified Metastable Materials, North Holland New York, (1983).

DOI: 10.1557/proc-28-87

[16] A. Tauqir, P.R. Strutt and P. G. Klemens A Model for Cellular Segregation in a Steel Generated by Fluid Flow Vorticity, Material Science & Engineering 94, pp.251-258, (1987).

DOI: 10.1016/0025-5416(87)90340-5

[17] B. A. Ahmed, et al. to be published.

[18] Information on http: /www. csun. edu/~bavarian/Courses/MSE%20227/Labs/9-Corrosion. pdf, June 20, (2011).
