Evaluation of Surface Roughness in High-Speed Shaping of Ni-P

Abstract:

A flat surface was machined by shaping to investigate the influence of the cutting speed on surface finish. When the cutting speed was 10-30 m/min, the surface roughness deteriorated because fine valleys with a depth of 40-200 nm were caused. Because the pitch of the valleys was almost equal at different cutting speeds, it was concluded that the valleys were not caused by the natural vibration of the machine tool. The velocity of the tool tip was measured by a laser Doppler vibrometer to compare the tool motion and the work piece profile. The periodical velocity change of the tool corresponded to the pitch of valleys. When a work piece with higher phosphorus content was machined, the valleys were not caused at a cutting speed of less than 30 m/min. It is estimated that the smoothness of chip removal has an influence on the emergence of valleys.

You might also be interested in these eBooks

Proceedings of Precision Engineering and Nanotechnology

View Preview

Info:

Periodical:

Key Engineering Materials (Volume 516)

Pages:

125-129

DOI:

https://doi.org/10.4028/www.scientific.net/KEM.516.125

Citation:

Cite this paper

Online since:

June 2012

Authors:

Daisuke Kono, Sho Nakade, Atsushi Matsubara

Keywords:

High-Speed Shaping, Nickel Phosphorus, Single Crystal Diamond Tool, Surface Roughness (SR)

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

References

[1] A. Pramanik, K. S. Neo, M. Rahman, X.P. Li, M. Sawa, Y. Maeda, Cutting performance of diamond tools during ultra-precision turning of electroless-nickel plated die materials,C. 140 (2003) 308-313.

DOI: 10.1016/s0924-0136(03)00751-9

Google Scholar

[2] A. Pramanik, K.S. Neo, M. Rahman, X.P. Li, M. Sawa, Y. Maeda, Ultra-precision turning of electroless-nickel: Effect of phosphorus contents, depth-of-cut and rake angle, J. Mater Process. Tech (2008) 400-408.

DOI: 10.1016/j.jmatprotec.2008.01.006

Google Scholar

[3] H. Eda, K. Kishi, H. Ueno, S. Masubuchi, Ultra precision cutting of electroless nickel plating layer, Journal of JSPE, 53 (1987) 814-819. (in Japanese).

DOI: 10.2493/jjspe.53.814

Google Scholar

[4] H. Eda, K. Kishi, H. Ueno, M. Oyatsu, For a long life of natural single crystal diamond tool, Journal of JSPE, 55 (1989) 161-166. (in Japanese).

Google Scholar
