EDM Properties of EC-PCD Manufactured Using Electrically Conductive Diamond Particles

Abstract:

Electrically conductive polycrystalline composite diamond (EC-PCD), which consists of electrically conductive diamond particles manufactured by doping boron atoms, has recently been developed for the purpose of providing material with both excellent tool properties and good machinability. This paper deals with an investigation into the machinability of EC-PCD by EDM with a copper electrode. As a result, it was found that the material removal rate of EC-PCD made up of diamond particles of 10 and 25 µm in diameter respectively was far higher than that of the conventional PCD. Furthermore, it was confirmed in the single pulse EDM experiment with a needle electrode that the EC diamond region in the EC-PCD was removed together with the cobalt region whereas only the cobalt region of C-PCD was removed when the electrode was set at plus polarity.

You might also be interested in these eBooks

Proceedings of Precision Engineering and Nanotechnology

View Preview

Info:

Periodical:

Key Engineering Materials (Volume 516)

Pages:

148-153

DOI:

https://doi.org/10.4028/www.scientific.net/KEM.516.148

Citation:

Cite this paper

Online since:

June 2012

Authors:

Shinichi Ninomiya, Manabu Iwai, Takuya Takada, Zhi Rong Zhou, Kiyoshi Suzuki

Keywords:

Boron Doped Diamond, EC-PCD, EDM Property, Electrically Conductive Diamond, PCD

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

References

[1] Y. Seki, S. Suzuki, T. Uematsu et al., Application of polycrystalline composite products (PCP) to a grinding wheel (1st report), Proceeding of JSAT Conf., ABTEC'96 (1996) 349-353. (in Japanese).

Google Scholar

[2] K. Suzuki, S. Sano, M. Iwai, T. Uematsu, et al., A new application of pcd as a very low wear electrode material for EDM, Proceeding of 2nd Int'l Industrial Diamond Conference (2007).

DOI: 10.4028/www.scientific.net/kem.291-292.549

Google Scholar

[3] K. Suzuki, Y. Shiraishi, M. Iwai, S. Ninomiya, Y. Tanaka, T. Uematsu, development of new PCD made up of boron doped diamond particles and its machinability by EDM, Adv. Mater. Res. 76-78 (2009) 684-689.

DOI: 10.4028/www.scientific.net/amr.76-78.684

Google Scholar

[4] K. Suzuki, S. Ninomiya, M. Iwai, et al., Wire EDM property of EC-PCD, Proceeding of JSAT Conf., ABTEC2009 (2009) 109-112. (in Japanese).

Google Scholar

[5] H. Minami, K. Watanabe, K. Masui, N. Nabekura, Electrical discharge truing for sintered polycrystalline diamond Tool, Journal of the Japan Society of Electrical Machining Engineers, 44 (2010) 17-24. (in Japanese).

DOI: 10.2526/jseme.44.17

Google Scholar
