Research on the Relationship between End Processing Technology and Processing Quality of Spiral Bevel Gear

Abstract:

The heated spiral bevel gear can improve service life and performance. However, the heated spiral bevel gear must be machined by the finish machining process, as result of deformation of tooth surface, which obtained lower machining accuracy. Due to the tooth surface particularity of spiral bevel gears, the traditional tooth grinding, lapping improve the processing quality of tooth surface was subject to a certain degree of influence. Therefore, some measures, such as flared cup grinding, waguri grinding and ultrasonic grinding, which not only improve processing quality of tooth surface of spiral bevel gear, but also improve mill efficiency. With the development of end processing technology at the same time, the cutting tool material and cutting methods appeared certain advantages and received attention in improving fine milling of hard tooth surface.

• Periodical: Key Engineering Materials (Volume 522)
• Pages: 31-35
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.522.31
• Online since: August 2012
• Authors: Ping Zhu, Adayi Xieeryazidan, Hong Xin Zhang
• Keywords: End Processing Technology, Lapping, Processing Quality, Tooth Grinding

References

[1] Compiled by Beijing Gear Factory: The Corpus of Technology Material of Gleason Bevel Gear (Mechanical industry Press, Beijing 1983). (In Chinese).

[2] T. Zeng: World Manufacturing Engineering & Market, (2006) No. 6, pp.79-83. (In Chinese).

[3] X.K. Wang: Machining Processing Handbook (Mechanical Industry Press, Beijing 2008). (In Chinese).

[4] M.Q. Cheng, J.J. Zhou and H.G. Wang: Journal of Dalian Engineering College, (1959) No. 3, pp.27-39. (In Chinese).

[5] Compiled by X.Q. Wang: World Manufacturing Engineering& Market, (1995) No. 4, pp.60-61. (In Chinese).

[6] Precision machinery limited company of Changsha Hongli: World Manufacturing Engineering& Market, (2002) No. 6, p.59. (In Chinese).

[7] N. Ma: Research on Spiral Bevel Gear Tooth Surfaces Finishing Using Pulse Electrochemical and Electrochemical Mechanical Methods (Ph.D., Dalian University of Technology, China 2010), pp.100-101. (In Chinese).

[8] B.Y. Wei, X.Z. Deng and Z.D. Fang: International Journal of Machine Tools & Manufacture, (2007) No. 47, p.2051-(2056).

[9] J.P. Sun: Mechanical Craftsman, (1997) No. 6, pp.31-32. (In Chinese).

[10] Y.D. Xie, J.J. Zhang, Z.Y. Wang, S.H. Cheng, G.H. Liu and M.D. Zhang: Automobile Gear, (2011) No. 1, pp.29-34. (In Chinese).
