The Image Positioning and Segmentation Techniques about Gauge Visual Detection System between High Signals and Contact Net Based on Target Feature

Abstract:

In the design process of gauge visual detection system between high signals and contact net, it is need to do target positioning and segmentation between high signals and contact line. The paper first analyzes the structural characteristics of high signals and contact line, and then uses the Sobel operator for edge detection, and uses first close and then open of image morphological operations for edge treatment, finally uses Hough transform for line and circle detection to extract the object's edge. This positioning and segmentation of target object would be achieved.
