Machining Trajectory Generation and Simulation of Miniature Integral Impeller

Abstract:

This paper describes machining trajectory generation and simulation of miniature integral impeller. Taking into account the closed and miniature of integral impeller, and low stiffness of the micro-milling tool, in order to avoid interference in the processing, through reasonably division of the impeller blade surface, generate the miniature integral impeller machining trajectory. Then impeller machining NC code is generated, and is simulated in Vericut software. Simulation result shows that the machining programs generated in this paper are effective, and the simulation machined workpiece surface is relatively smooth.

• Periodical: Key Engineering Materials (Volume 522)
• Pages: 355-358
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.522.355
• Online since: August 2012
• Authors: Xiang Zhang, Xu Dong Pan, Guang Lin Wang
• Keywords: Machining Simulation, Machining Trajectory, Miniature Integral Impeller, Region Division

References

[1] L. Zhang, N.Z. Yun and Z.G. Guo: Electromachining & Mould, Vol. 2 (2003), p.29 (In Chinese).

[2] C.F. Huang: Aeronautical Manufacturing Technology, Vol. 4 (2006), p.94 (In Chinese).

[3] S.F. Zhao, N.Z. Yun, W.Y. Xu, et al: Aeronautical Manufacturing Technology, Vol. 4 (2004), p.86 (In Chinese).

[4] X.H. Xiong, H.O. Zhang, G.L. Wang, et al: Robotics and Computer-Integrated Manufacturing, Vol. 26 (2010), p.291 (In Chinese).

[5] X. Zhang, Z.Y. Han, Y. Z. Sun, et al: Key Engineering Materials, Vol. 431-432 (2010), p.78 (In Chinese).
