Study on Noise in New Roller Chain Drives

Abstract:

In order to mitigate the impact and the polygon effect of the chain and the sprocket during the meshing process and achieve the purpose of noise reduction, a Hlow noiseH nanostructured metal mesh-polyurethane composite material split roller chain was designed by means of changing structure and material of chain roller. Noise testing and frequency spectrum analysis were conducted, for the new roller chain and the other three kinds of the same specification chains with different structural rollers, on the closed force flow noise test bench researched and developed independently. The results show that the new roller chain can absorb some of the impact energy, and reduce vibration and noise of chain drive. The noise level generated by the new roller chain is significantly lower than the other tested roller chains, especially in high frequency and high speed. The difference in noise level is actually 3-11dB in driving sprocket speed of 1000r/min, and a significant noise reduction is achieved. The results also verify low noise characteristics of the new roller chain and rationality of design method.

You might also be interested in these eBooks

Progress in Advanced Manufacturing Technologies

View Preview

Info:

Periodical:

Key Engineering Materials (Volume 522)

Pages:

598-601

DOI:

https://doi.org/10.4028/www.scientific.net/KEM.522.598

Citation:

Cite this paper

Online since:

August 2012

Authors:

Wei Sun, Xiao Lun Liu, Wen Cheng Wang, Li Yan He, Jia Jun Liu

Keywords:

Chain Drive, Meshing Impact, Noise Reduction, Split Roller

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

References

[1] S.P. Liu, K. W. Wang, S. I. Hayek, M. W. Trethewey and K. H. K. Chen: Journal of Sound and Vibration, Vol. 203 (1997) No. 1, pp.41-62.

Google Scholar

[2] J. A. Calvo, V. Diaz, J.L. San Roman and M Ramirez: Int. J. Vehicle Noise and Vibration, Vol. 2 (2006) No. 1, pp.75-89.

Google Scholar

[3] S. K Wang, F.Z. Meng, Q.H. Li and S.H. Sun: Acta Armamentarii, Vol. 30(2009) No. 6, pp.759-763.

Google Scholar

[4] F. Z Meng. The Meshing Principle of Silent Chain (China Machine Press, China 2008). (In Chinese).

Google Scholar

[5] Z.F. Zheng, Y.X. Wang and B.H. Chai: Chain Drive (Machinery Industry Press, China 1984). (In Chinese).

Google Scholar

[6] Z.G. Yang, Z.F. Zheng and W.D. He: Mechanical Design, Vol. 11(1994) No. 3, pp.22-24.

Google Scholar

[7] H. Lan, R.G. Zhang, C. Jin, J.J. Yang, C. J Guo: Noise and Vibration Control, Vol. 25(2005) No. 4, pp.61-63.

Google Scholar

[8] SR Turnbull, SW Nicol and JN Faweett: ASME (New Orleans, U.S.A. Jan. 23-27, 1994) Vol. 1, pp.26-30.

Google Scholar
