Numerical Simulation of Transmission Laser-Welding Melting Depth on Thermoplastic

Abstract:

The principle of laser welding of combined translucent thermoplastic and absorbance thermoplastics is that laser transmit through translucent material and shoot at laser absorptive material, where the material absorb energy and melt down to complete welding. This paper studied the applicability of basic law of laser transmission welding beam mechanism and light absorption process – Beer-Lamber Law to plastic materials. Numerical simulation model of melting depth was established. Single factor relevance curve and double factor relevance surface were drawn with MATLAB; Impact of laser power, distance between weld zone and lens and scanning speed to melting depth was quantitatively analyzed on melting depth, which provided effective reference for setting parameters in the experiment.

• Periodical: Key Engineering Materials (Volume 522)
• Pages: 68-71
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.522.68
• Online since: August 2012
• Authors: Zhen Wang, Yun Shan Wang, Jian Bo Lei
• Keywords: Laser Technology, Melting Depth, Numerical Simulation, Translucent Material, Transmission Laser-Welding

References

[1] L.S. Mayboudi, A. M . Birk and G. Zak: Journal of Laser Applications, Vol. 21 (2009) No. 3, pp.111-118.

[2] L.S. Mayboudi, A.M. Birk and G. Zak: Journal of Laser Applications, Vol. 22 (2010) No. 1, pp.22-28.

[3] J.C. Li: Laser Diffraction and Thermal Effects Calculation (Science Press, China 2008).

[4] V.A. Kagan, R.G. Bray and W.P. Kuhn: Journal of Reinforced Plastics and Composites, Vol. 21 (2002), pp.1101-1121.
