Theoretical Investigation of an Optical Vibration Using Laser Beams from Optical Fibers Inserted at an Angle of 35 Degrees

Abstract:

Optical trapping is a technique that is used to capture, translate, and manipulate microscopic particles, such as dielectric microspheres and cells. This cell manipulation and examination technology can be integrated on a Lab-on-a-Chip device. We have already developed an optically vibration system. The optical vibration system was formed using a temperature stabilized 1480nm cw diode laser. The output of laser light was coupled into optical fibers, which had optical connectors at these fiber ends. The fiber end had a hemispherical micro-lens with 5μm radius of curvature for focusing the laser beam emerging from the optical fiber end. These trapping fibers were attached to xyz manipulators and were inserted into a sample cell at an angle of 35 degrees. The trapped microsphere, 10μm diameter polystyrene particle (refractive index 1.59), could be optically vibrated by controlling laser power emerging from optical fibers. We theoretically analyzed the optical forces exerted on a microsphere by laser beams. Its operating principle is based upon the conservation of photon momentum carried by the incident laser light on a trapped microsphere. From these theoretical results, we verified that our proposed optical manipulation technique was useful for the manipulation of biological cells.

You might also be interested in these eBooks

Emerging Technology in Precision Engineering XIV

View Preview

Info:

Periodical:

Key Engineering Materials (Volumes 523-524)

Pages:

1059-1064

DOI:

https://doi.org/10.4028/www.scientific.net/KEM.523-524.1059

Citation:

Cite this paper

Online since:

November 2012

Authors:

Nobuyuki Watanabe, Kozo Taguchi

Keywords:

Biological Cell, Laser Beam Effects, Optical Fiber, Optical Trapping, Theoretical Analysis

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

References

[1] A.Ashkin, J.M. Dziedzic and T.Yamane: "Optical trapping and manipulation of single cells using infrared laser beams", NATURE: 330 (1987) 769–771.

DOI: 10.1038/330769a0

Google Scholar

[2] K. Taguchi, K. Atsuta, T. Nakata, and Masahiro Ikeda: "A Possible Manipulation of a Biological Cell by a Laser Beam Focused through Optical Fiber", IEICE TRANS ELECTRON: 83-C (2000) 664–667.

Google Scholar

[3] Kozo Taguchi, Kenji Ogawa "Optically Vibrated Manipulation Technique of a Microsphere in a Liquid Using Plural optical fibers" Journal of Physics: Conference Series 61 (2007) 1132-1136.

DOI: 10.1088/1742-6596/61/1/224

Google Scholar

[4] K. Taguchi, K. Atsuta, T. Nakata, and Masahiro Ikeda: "Experimental Analysis of Optical Trapping System Using Tapered Hemispherical Lensed Optical Fiber", OPTICAL REVIEW: 6 (1999) 224-226.

DOI: 10.1007/s10043-999-0224-z

Google Scholar
