Effect of Ultrasonic Vibration Drilling on Cutting Stress Distribution

Abstract:

A drill processing for the difficult to cut material such as ceramics, hardened steel, glass and heat-resistant steel is widely requested in the industrial world. Furthermore the drilling process becomes more and more difficult in the case of that the requested hole diameter is less than one millimeter. In order to achieve requirements for drilling process, ultrasonically assisted machining is applicable. Ultrasonic vibration assisted machining techniques are suitable to machine difficult-to-cut materials precisely. The ultrasonic vibration assisted sub-millimeter drilling process reduces the cutting forces and prevents severe wear of tools. However, it is difficult to observe directly the effect of vibration action because the process of ultrasonic drilling is dynamic instantaneous and micro cutting process. In this report, high speed camera with appropriately arranged polarized device realized the visualization of process of ultrasonic drilling based on the photoelastic analysis. For the conventional drilling, the stress distribution diagram showed the intensive stress occurred under the chisel and side wall. On the other hand, the ultrasonic drilling produced lower and stable cutting force and decreased the tool temperature.

• Periodical: Key Engineering Materials (Volumes 523-524)
• Pages: 191-196
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.523-524.191
• Online since: November 2012
• Authors: Hiromi Isobe, Yusuke Uehara, Keisuke Hara
• Keywords: Photoelastic Image, Stress Distribution, Ultrasonic Drilling, Ultrasonic Machining

References

[1] D.E. Brehl, T.A. Dow, Review of Vibration-assisted Machining, Prec Eng, 32 (2007)153-172.

[2] R.Neugebauer, A.Stoll, Ultrasonic Application in Drilling, Jounal of Material Processing Technology, 149 (2004) 633-639.

DOI: 10.1016/j.jmatprotec.2003.10.062

[3] S.S.F. Chang, G.M. Bone, Burr Size Reduction in Drilling by Ultrasonic Assistance, Robotics and Computer-Integrated Manufacturing, 21(2005)442-450.

DOI: 10.1016/j.rcim.2004.11.005

[4] B. Azarhoushang, J.Akabari, Ultrasonic-assisted drilling of Inconel 738-LC, Int J Machine Tools and Manuf, 47 (2008) 1027-1033.

DOI: 10.1016/j.ijmachtools.2006.10.007

[5] Y.S. Liao, Y.C. Chen, H.M. Lin, Feasibility Study of the Ultrasonic Vibration Assisted Drilling of Inconel Superalloy, Int J of Machine Tools and Manuf, 47(2007) 1988-1996.

DOI: 10.1016/j.ijmachtools.2007.02.001

[6] J. Du. Kim and I. Hyu Choi, Characteristics of Chip Generation by Ultrasonic Vibration Cutting with Extremely Low Cutting Velocity, International Journal of Advanced Manufacturing Technology, 14 (1998) 2-6.

DOI: 10.1007/bf01179410

[7] Hobbs, J. W., Grene, R. J. And Patterson, E. A., A novel Instrument for Transient Photoelasticity, Exp. Mech., 43-4 (2003)403-409.
