Development of Wire-Connected Mechanism for Precise Positioning

Abstract:

Micro/nano positioning is one of important techniques to operate bio-cell and micro assembly. For realizing the precise positioning, the various piezo-driven stages have been already proposed and micro/nano scale resolution has been achieved. However, it is pointed out that the existing precision positioning tools are too large compared to operating area. Their devices are too difficult to combine other devices and use in tight environment like under microscope. In this paper, a precise positioning method with wire connected mechanism under microscope is proposed. The proposed positioning system is simply composed actuators including piezoelectric element and super extra-fine wires. By applying wire connected mechanism, the saving of larger work environment compared to traditional devices is hoped.

• Periodical: Key Engineering Materials (Volumes 523-524)
• Pages: 645-649
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.523-524.645
• Online since: November 2012
• Authors: Masahiro Shinoda, Shinnosuke Hirata, Hisayuki Aoyama
• Keywords: Piezoelectric Actuator, Precise Positioning, Wire-Connected System

References

[1] Ohmi Fuchiwaki, Daigo Misaki, Hisayuki Aoyama, "Flexible Microprocessing Organized by Versatile Microrobots", 7th Int. Conference on Mechatronics Technology, pp.121-126, Taipei, China, 2003.

[2] Sadao Kawamura, Won Choe, Satoshi Tanaka, Shunmugham R. Pandian, "Development of an Ultrahigh Speed Robot FALCON using Wire Drive System", Proc. of the IEEE International Conference on Robotics and Automation, pp.215-220, Nagoya, Japan, 1995.

DOI: 10.1109/robot.1995.525288

[3] Geoff Mroz, Leila Notash, "Design and Prototype of Parallel, Wire-Actuated Robots with a Constraining Linkage", Journal of Robotic Systems, vol. 21, No.12, pp.677-687, 2004.

DOI: 10.1002/rob.20044

[4] Chihiro Kozuka, Daisuke Yamaguchi, Yasutaka Tagawa, Masaki Hayatsu, Sachio Maekawa,"Vibration Control Technique in Wire-Driven Pararell Mechanism", Dynamics & Design Conference, Vol.2003, No.Pt.2, pp.333-337, 2003.

DOI: 10.1299/jsmedmc.2003._163-1_

[5] Hiroshi Kaizuka, Byron Siu,"A Simple Way to Reduce Hysteresis and Creep When Using Piezoelectric Actuators", Japanese Journal of Applied Physiscs, Vol. 27, No.5, pp.773-776, 1988.

DOI: 10.1143/jjap.27.l773

[6] Katsushi Furutani, Atsushi Furuta, "Comparison of Driving Performance of Piezoelectric Actuator – Current Pulse Drive and Voltage Linear Drive –", Service Robotics and Mechatronics, pp.183-188, 2009.

DOI: 10.1007/978-1-84882-694-6_32
