Design and Test of a Three-Axis Mosaic Surface Encoder

Abstract:

A three-axis mosaic surface encoder, which can measure the X-directional position and the Y-, Z-directional straightness of the linear stage in a long range, is proposed. The three-axis mosaic surface encoder is composed of multiple scanning probes and a mosaic scale grating. The mosaic scale grating is constructed by placing the multiple two-dimensional reflective-type scale gratings in a line to obtain long measurement range along the in-plane direction of a scale grating. In addition, the optical configuration of the encoder head, which employs multiple scanning probes to be projected on the mosaic scale grating, is proposed so that a long range measurement can be achieved by the mosaic scale gratings. With the proposed encoder head, the measurement information of the X-directional displacement can always be obtained from the probe which is not on the gaps of the mosaic scale grating. The proposed configuration was applied to the three-axis surface encoder, and basic performances of the proposed three-axis mosaic surface encoder are experimentally investigated.

You might also be interested in these eBooks

Emerging Technology in Precision Engineering XIV

View Preview

Info:

Periodical:

Key Engineering Materials (Volumes 523-524)

Pages:

919-924

DOI:

https://doi.org/10.4028/www.scientific.net/KEM.523-524.919

Citation:

Cite this paper

Online since:

November 2012

Authors:

Woo Jae Kim, Yuki Shimizu, Koji Hosono, So Ito, Wei Gao

Keywords:

Linear Stage, Mosaic Grating, Multiple-Probe, Optical Sensor, Position Measurement

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

References

[1] Linear Encoders Catalogue, Heidenhain GmbH, Germany.

Google Scholar

[2] Kunzman, H, Pfeifer T. and Fluggle J., Scales vs. laser interferometers performance and comparison of two measuring systems, Annual of the CIRP, Vol.42, No. 2 (1993), pp.753-767.

DOI: 10.1016/s0007-8506(07)62538-4

Google Scholar

[3] A. Kimura, W. Gao, Y. Arai, Z. Lijiang, Design and construction of a two-degree-of-freedom linear encoder for nanometric measurement of stage position and straightness, Precision Engineering, Vol.34, No.1 (2010), pp.145-155.

DOI: 10.1016/j.precisioneng.2009.05.008

Google Scholar

[4] W.Gao, A.Kimura, A Three-axis Displacement Sensor with Nanometric Resolution, Annals of the CIRP, Vol.56, No.1 (2007), pp.529-532.

DOI: 10.1016/j.cirp.2007.05.126

Google Scholar

[5] INTERNATIONAL TECHNOLOGY ROADMAP FOR SEMICONDUCTORS, ITRS 2009 EDITION, Executive Summary, (2009).

Google Scholar
