Experimental Research on Fracture Toughness of High Grade Line Pipe

Abstract:

Crack tip opening displacement (CTOD) tests were carried out on different positions of X70, X80 and X100 pipe by three-point bend testing method. The results show that the crack propagation resistance and the tear modulus of base metal, heat affected zone (HAZ), and weld of X70 and X80 pipe are larger than that of X100 pipe. At the same time,The initial CTOD values and the CTOD values withmaximum load of X70 and X80 pipe are larger than that of X100 pipe.The test results suggest that the fracture toughness, crack initiation and propagation resistance of theX70 and X80 pipe are greater than that of X100 pipe, and the mechanismis analyzed finally.

• Periodical: Key Engineering Materials (Volumes 525-526)
• Pages: 425-428
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.525-526.425
• Online since: November 2012
• Authors: Qing Ren Xiong, Jian Xun Zhang, Yao Rong Feng, Hai Tao Wang, Qiu Rong Ma, Zhen Zhen Xu
• Keywords: CTOD Test, Fracture Toughness, High Grade Line Pipe

References

[1] HILLENBRAND H G. Development of linepipe in grade up to X100 [C]/Proceedings of the 11th EPRG/PRCI Biennial Joint Technical Meeting on Pipeline Research. Pipeline research council international, Arlington, Massachusetts , USA, 1997：pp.6-10.

[2] HILLENBRAND H G, KALWA C. High strength line pipe for project cost reduction [J]. World Pipelines, 2002, 2(1): pp.1-10.

[3] Glover A. Application of grade 555 (X80) and 690 (X100) in Arctic climates [C]/Proceedings of Application & Evaluation of High Grade Linepipe in Hostile Environments Conf. Scientific Surveys Ltd., Yokohama, Japan, Nov, 2002: p.33~52.

[4] Barsanti L. From X80 to X100: know-how reached by ENI Group on high strength steel [C]/Proceedings of Application & Evaluation of High Grade Linepipe in Hostile Environments Conf. Scientific Surveys Ltd., Yokohama, Japan, Nov. 2002: p.231 ~ 244.

[5] FAIRCHILD D P. High strength steels – beyond X80 [C]/Proceedings of Application & Evaluation of High Grade Linepipe in Hostile Environments Conf. Scientific Surveys Ltd., Yokohama, Japan, Nov. 2002: p.307~321.

[6] BARSANTI L, HILLENBRAND H G, MANNUCCI G, et al. Possible use of new materials for high pressure linepipe construction: an opening on X100 grade steel [C]/Proceedings of 4th International Pipeline Conference. American Society of Mechanical Engineers, Calgary, Alberta, Canada, 2002: p.287.

DOI: 10.1115/ipc2002-27089

[7] ASTM-E1290-2007. Standard Test Method for Crack-Tip Opening Displacement (CTOD) Fracture Toughness Measurement[S]. Philadelphia, USA, American Society for Testing and Materials, (2007).

DOI: 10.1520/e1290-02

[8] Deng Caiyan, Zhang Yufeng, Huo Lixing, et. al. The fracture toughness of welding jiont of X65 line pipes by CTOD tests [J]. Transactions of the China Welding Institution, 2003, 53(3): 13-16.

[9] Liu Shouxian. Reseaches about X100 line pipes [D]. Kunming：Kunming University of Science and Technology, Materials and Metallurgy Engineering, (2007).
