Electro-Mechanical Impedance Technique for Structural Health Monitoring of Composite Panels

Abstract:

Numerical modelling of EMI for damage detection has been presented in this paper. The PZT model is validated against the published experimental result for free disk and tied to the structure. The numerical modelling of the PZT patch will result in the admittance measure of the structure. The imaginary part of the admittance measure is used for developing a self-diagnostic sensor system. The real part of the admittance measure was used to develop a damage detection algorithm. Damage detection using EMI method was successfully applied to a simple composite disk and a stiffened panel. The EMI method is suitable for short range damage detection in structural parts with limited or no access.

• Periodical: Key Engineering Materials (Volumes 525-526)
• Pages: 569-572
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.525-526.569
• Online since: November 2012
• Authors: Martin Schwankl, Z. Sharif-Khodaei, Ferri M.H.Aliabadi, Christian Weimer
• Keywords: Damage Detection, Electro-Mechanical Impedance, Structural Health Monitoring (SHM)

References

[1] STASZEWSKI, W. J., BOLLER, C., & TOMLINSON, G. R. (2004). Health Monitoring of Aerospace Structures: Smart Sensor Technologies and Signal Processing. Chichester: John Wiley & Sons Ltd.

DOI: 10.1002/0470092866

[2] SHARIF KHODAEI Z., ROJAS-DIAZ R. & ALIABADI M.H. (2012). Lamb-wave Based Technique for Impact Damage Detection in Composite Stiffened Panels. Key Engineering Materials Vols. 488-489 pp.5-8.

DOI: 10.4028/www.scientific.net/kem.488-489.5

[3] LIANG, C., SUN, F., & ROGERS, C. (1994). Coupled Electro-Mechanical Analysis of Adaptive Material Systems - Determination of Actuator Power Consumption and System Energy Transfer. Journal of Intelligent Material and Systems Structures.

DOI: 10.1177/1045389x9400500102

[4] NAIDU, A., & SOH, C. (2004). Identifying damage location with admittance signatures of smart piezo-transducers. Journal of Intelligent Material Systems and Structures.

DOI: 10.1177/1045389x04043269

[5] ANNAMADAS, V., & SOH, C. (2009). Application of Electromechanical Impedance Technique for Engineering Structures: Review and Feature Issues. Journal of Intelligent Material Systems and Structures.

DOI: 10.1177/1045389x09352816

[6] GIURGIUTIU, V., & ROGERS, C. (1998). Recent Advancements in the Electro-Mechanical (E/M) Impedance Method for Structural Health Monitoring and NDE. Proc. SPIE 3329.

[7] ZAGRAI, A. N. (2002). Piezoelectric-Wafer active sensor Electro-Mechanical Impedance Structural Health Monitoring. University of South California.
