Influence of Surface Morphology on the Tribological Behavior of Diamond-Like Carbon Coating

Abstract:

Diamond-like carbon (DLC) films were prepared in-situ on top of hard coatings, namely, prior to the DLC deposition, CrN, TiCN and nanocomposite nACo (nc-AlTiN/(a-Si3N4) layers were deposited on WC-Co substrates. The Ra roughness of WC-Co substrates was 0.05 and 0.2 µm. Surface morphology of DLC coatings was investigated by means of profilometry and geometrical parameters Ra, Rsk, Rku and Rz were evaluated. Fretting tests were conducted with 3 mm in diameter alumina balls under 1 and 2 N load, at slip distance of 2 mm and frequency of 2 Hz. Statistical analysis shows significant correlation between Ra and Rz parameters corresponding to initial DLC surface and wear scar surfaces produced by fretting tests after 2400 and 4800 cycles, respectively. This finding indicates a relationship between friction (wear) and Ra and Rz parameters. Positive correlation between the coefficient of friction (COF) and kurtosis Rku indicates that surface flatness is an important factor for optimal friction of an alumina ball against DLC coating.

• Periodical: Key Engineering Materials (Volume 527)
• Pages: 83-91
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.527.83
• Online since: November 2012
• Authors: Vitali Podgursky, Andrei Bogatov, Martin Freund, Priit Kulu
• Keywords: Diamond-Like Carbon (DLC), Friction, Surface Morphology

References

[1] A. Erdemir, C. Donnet, Tribology of diamond-like carbon films: recent progress and future prospects, Journal of Physics D. 39 (2006) R311–R327.

DOI: 10.1088/0022-3727/39/18/r01

[2] K. Holmberg, H. Ronkainen, A. Laukkanen, K. Wallin, Friction and wear of coated surfaces scales, modelling and simulation of tribomechanisms, Surface & Coating technology. 202 (2007) 1034-1049.

DOI: 10.1016/j.surfcoat.2007.07.105

[3] J. Robertson, Diamond-like amorphous carbon, Materials Science and Engineering. 37 (2002)129–281.

[4] J. Jiang, R.D. Arnell, The effect of substrate surface roughness on the wear of DLC coatings, Wear. 239 (2000) 1–9.

DOI: 10.1016/s0043-1648(99)00351-8

[5] T. Ohana, M. Suzuki, T. Nakamura, A. Tanaka, Y. Koga, Tribological properties of DLC films deposited on steel substrate with various surface roughness, Diamond & Related Materials. 13 (2004) 2211– 2215.

DOI: 10.1016/j.diamond.2004.06.037

[6] B. K. Gupta, A. Malshe, B. Bhushan and V. Subramaniam, Friction and wear properties of chemomechanically polished diamond films, J. Tribology. 116 (1994) 445-453.

DOI: 10.1115/1.2928862

[7] P.J. Blau, On the nature of running-in, Tribol. Int. 38 (2005) 1007–1012.

[8] P.J. Blau, Interpretations of the friction and wear break-in behavior of metals in sliding contact, Wear. 71 (1981) 29–43.

DOI: 10.1016/0043-1648(81)90137-x

[9] C. A. Kotwal, and B. Bhushan, Contact analysis of non-Gaussian surfaces for minimum static and kinetic friction and wear, Tribology Transactions. 39(4) (1996) 890-898.

DOI: 10.1080/10402009608983609

[10] S. Chandrasekaran, S. Sundararajan, Effect of microfabrication processes on surface roughness parameters of silicon surfaces, Surf. Coat. Technol. 188-189 (2004) 581-587.

DOI: 10.1016/j.surfcoat.2004.07.015

[11] V. Podgursky, R. Nisumaa, E. Adoberg, A. Surzhenkov, A. Sivitski, P. Kulu, Comparative study of surface roughness and tribological behavior during running-in period of hard coatings deposited by lateral rotating cathode arc, Wear. 268 (2010) 751-755.

DOI: 10.1016/j.wear.2009.11.016

[12] V. Podgursky, E. Adoberg, A. Surženkov, E. Kimmari, M. Viljus, V. Mikli, M. Hartelt, R. Wäsche, M. Šíma, P. Kulu, Dependence of the friction coefficient on roughness parameters during early stage fretting of (Al,Ti)N coated surfaces, Wear. 271 (5–6) (2011) 853-858.

DOI: 10.1016/j.wear.2011.03.006

[13] J.M. Lackner, W. Waldhauser, R. Berghauser, R.Ebner, B.Major, T.Schöberl, Structural, mechanical and tribological investigations of pulsed laser deposited titanium nitride coatings, Thin Solid Films. 453-454 (2004) 195-202.

DOI: 10.1016/j.tsf.2003.11.106

[14] A. C. Ferrari and J. Robertson, Resonant Raman spectroscopy of disordered, amorphous, and diamond like carbon, PRB 64 (2001) 075414-1 - 075414-13.

[15] B. Bhushan, Modern Tribology Handbook, CDC Press, 2001, p.49–80.

[16] T. Hill and P. Lewicki, Statistics (Methods and Applications), StatSoft Inc., 2006.

[17] W. Wieleba, The statistical correlation of the coefficient of friction and wear rate of PTFE composites with steel counterface roughness and hardness, Wear. 252 (2002) 719–729.

DOI: 10.1016/s0043-1648(02)00029-7

[18] P. L. Menezes, K. Kailas and S.V. Kailas, Influence of roughness parameters on coefficient of friction under lubricated conditions, Sādhanā. 33 (3) (2008)181–190.

DOI: 10.1007/s12046-008-0011-8

[19] B. Bhushan, V. V. Subramaniam, A. Malshe, B. K. Gupta, and J. Ruan, Tribological properties of polished diamond films, J. Appl. Phys. 74 (1993) 4174–4180.

DOI: 10.1063/1.354421

[20] A. Hirata, N. Yoshioka, Sliding friction properties of carbon nanotube coatings deposited by microwave plasma chemical vapor deposition, Tribol. Int. 37 (2004) 893-898.

DOI: 10.1016/j.triboint.2004.07.005

[21] E. Kimmari. V. Podgursky, M. Simunin, E. Adoberg, A. Surženkov, M. Viljus, M. Hartelt, R. Wäsche, I. Sildos, P. Kulu, Tribological behavior of carbon nanofibers deposited on superhard nanocomposite nACo coating, Submitted to Tribology International.

DOI: 10.1016/j.surfcoat.2013.03.011

[22] John Mandel, The statistical analysis of Experimental data, Dover Publications Inc. New York, 1984, p.55.
