Quality Assurance of Laser Welded Axisymmetric Sandwich Structure

Abstract:

This study focuses on quality assurance in a laser welded axisymmetric sandwich structure that functions as the body of an electric machine. The manufacturing quality of the structure was measured using destructive testing and visual inspection. The destructive tests included both fatigue and static tests in addition to a macrographic examination. The visual inspection comprised ocular estimates of the laser welded seams as well as their requirements. Compared with the real working conditions of the machine, the experimental tests were exhaustive. Nevertheless, in the tests, the bodies held up very well which shows the great strength of the structure.

• Periodical: Key Engineering Materials (Volume 549)
• Pages: 529-534
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.549.529
• Online since: April 2013
• Authors: Kimmo Illikainen, Kalle Holappa, Kari Mäntyjärvi
• Keywords: Laser Welding, Quality Assurance, Sandwich Structure

References

[1] J Hietala & P Järvelä: Kennorakenteiden tekninen käyttö, Tampere: Tampereen teknillinen korkeakoulu, Materiaaliopin laitos (2001)

[2] P. Kujala, J Romanoff, A Salminen, J Varis & M Vilpas: Teräksiset kerroslevyrakenteet, Helsinki: Metalliteollisuuden keskusliitto MET (2003)

[3] H Allen: Analysis and design of structural sandwich panels, Oxford: Pergamon Press (1969)

[4] J Ion: Laser processing of engineering materials, Oxford: Butterworth Heinemann. (2005)

[5] Design for laser manufacture, http://www.designforlasermanufacture.com/17/Lightweight_sandwich_panel.html (2011)

[6] V Kujanpää, A Salminen & J Vihinen: Lasertyöstö. Helsinki: Teknologiateollisuus ry. (2005), p.246
