Structure Design and Finite Element Analysis of Receiving System for Optical Communication

Abstract:

Along with the rapid development of science and technology, and due to the special advantage of laser communication, such as big traffic and good secrecy, the application of optical communication is more and more wide. One of key technologies is the structure design of receiving system. In this paper, a structure of receiving system for optical communication based on Cassegrain system is introduced. Consist of the support structure of primary mirror and secondary mirror, adjustment structure of secondary mirror, structure design of reflectors, etc. FEM is used to analyze the distortion of primary mirror which is based on this structure. The distortion is caused by pressure, self-weight and temperature change, etc. And the stress deformation of primary mirror tube is analysed particularly. Analysis and test results demonstrate that the design project is reasonable.
