The Structural Design Method of Multi-Layer Parabolic Reflective Surface for X-Ray Focusing

Abstract:

As an ultra-short electromagnetic waves, X-ray has a strong ability to penetrate with high-energy. The method for focusing visible spectral bands is not suitable for X-ray spectrum. At present, in X-ray astronomy, the X-ray focus mode which uses grazing incidence less than critical angle has been widely used. However, the small critical angle limits its effective aperture of the X-ray collection. This paper presents a multi-layer reflective structure working with grazing incidence and the surfaces coated multilayer high reflective for X-ray. It can guarantee the large effective entrance pupil and high energy collection. The 200mm diameter X-ray focusing device is designed as an example. It is found from simulation that a good focusing result is acquired.

• Periodical: Key Engineering Materials (Volume 552)
• Pages: 75-78
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.552.75
• Online since: May 2013
• Authors: Miang Zhao Ouyang, Yue Gang Fu, Zhi Ying Liu, Jia Ke Wang, Wen Jun He
• Keywords: Multi-Layer Parabolic Reflective Surface, X-Ray Focusing

References

[1] LI Yude,LIN Xiaoyan,DU Shucheng." A discussion on X-ray reflectivity"[J],COLLEGE　PHYSICS, Mar.2006, Vol.25 No.3

[2] Ding Xunliang, Xie Jingdong, He Yejun, et al."X-ray spectrometry using polycapillary X-ray optics and position sensitive detector"[J].Talanta,2000,53:17~22.

DOI: 10.1016/s0039-9140(00)00387-8

[3] B.L. Henke, "Low energy X-ray spectroscopy with crystals and multilayers", University of hanwaii, Depatment of physics and astronomy, Honolulu, Hawii96822

[4] Q in Junling , Yi Kui , Shao Jianda , Fan Zheng xiu," Soft X
Ray Reflectivity of Periodic Graded
index Multilayers" ACTA PHOT ON ICA SINICA, Aug ust 2006, Vol. 35 No. 8
