Partial Joining of Blanks with Electrochemical Support (ECUF)

Abstract:

Hybrid materials offer great potential for weight and cost reduction, function integration and improved mechanical properties. A whole range of parts or application areas are conceivable (especially in the field of lightweight design). In terms of implementation, it is possible to produce fully or partially joined semi-finished parts from metallic, organic or inorganic materials. Semi-finished parts of this type can be used in applications ranging from simple reinforcements to complex hollow structures in automobiles. Innovative production processes are necessary for the efficient manufacture of these parts. This is why the current research and development work is focused on making complex, hollow work pieces from hybrid semi-finished materials and on manufacturing methods for the partially joined semi-finished parts. A new and innovative incremental joining process with inline electrochemical treatment is opening up interesting perspectives here. For the manufacture of complex work pieces, the use of adapted sheet-metal-forming processes, like deep drawing or working-media-based high pressure forming, is highly promising and will be addressed in the paper.

• Periodical: Key Engineering Materials (Volumes 554-557)
• Pages: 1091-1095
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.554-557.1091
• Online since: June 2013
• Authors: Hans Christian Schmidt, Werner Homberg, Guido Grundmeier, Hans Jürgen Maier
• Keywords: Hybrid Material, Incremental Joining, Light-Weight Design, Partial Cladding, Partial Joining, Sheet Metal Forming, Surface Activation

References

[1] Kleiner, M., Geiger, M., Klaus, A., Manufacturing of Lightweight Components by Metal Forming, CIRP Annals – Manufacturing Technology 52/2 (2003) pp.521-542.

DOI: 10.1016/s0007-8506(07)60202-9

[2] Birkert, A., Neubert, J., Gruszka, T., Hydrostatisches Aufweiten von verschweißten Doppelplatinen, in: Siegert, K. (Ed.), Hydroforming von Rohren, Strangpreßprofilen und Blechen, MAT-INFO, Frankfurt, 1999, pp.327-341.

[3] Homberg, W., Tekkaya, A. E., Beerwald, C., Brosius, A., Dau, J., Trompeter, M., Multifunctional Lightweight Structures from Tailored Cladded Aluminum Blanks, Key Engineering Materials 410-411 (2009) pp.37-42.

DOI: 10.4028/www.scientific.net/kem.410-411.37

[4] Schmidt, H.C., Homberg, W., Effiziente Herstellung hybrider Strukturbauteile aus Stahl und CFK, in: Neugebauer, R., Drossel, W.G. (Eds.), 19th Saxon Conference on Forming Technology SFU (Proceedings), Verlag Wissenschaftliche Scripten, Chemnitz, 2012, pp.195-203.

[5] Merklein, M., Geiger, M., Celeghini, M., Combined tube and double sheet hydroforming for the manufacturing of complex parts, CIRP Annals – Manufacturing Technology 54/1 (2005) pp.199-204.

DOI: 10.1016/s0007-8506(07)60083-3

[6] Zhang, W., Bay, N., Cold Welding - Experimental Investigation of the Surface Preparation Methods, Welding Journal 8 (1997) pp.326-330.

[7] Ogura, K., Sato, K., Cathodic Dissolution of the Passive Film on Iron – I. Kinetics and Mechanism, Electrochimica Acta 25 (1980) pp.857-862.

DOI: 10.1016/0013-4686(80)90038-9

[8] Su, Y.Y., Nakayama, S., Osakai, T., Cathodic reduction of copper oxides, Corrosion Reviews 1-2/29 (2011) pp.51-71.

DOI: 10.1515/corrrev.2011.001

[9] Bowden, F.P. and Tabor, D., The Friction and Lubrication of Solids, Clarendon Press, Oxford, 1986.

[10] Homberg, W., Dau, J., Verfahren zur umformtechnischen Herstellung von Halbzeugen mit lokal variierenden bzw. einstellbaren Verbundeigenschaften, entsprechend hergestellte Halbzeuge sowie Verwendung entsprechender Halbzeuge. Deutsches Patent- und Markenamt, DE 10 2010 025 963 A1, issued 30 June 2010, Patent application.
