Finite Element and Experimental Investigation of the Multipoint Flexible Hydroforming

Abstract:

FINITE ELEMENT AND EXPERIMENTAL INVESTIGATIONS OF THE MULTI-POINT FLEXIBLE HYDOFORMING. N. Selmi*, H. BelHadjSalah* *Mechanical Engineering Laboratory (LGM), National Engineering School of Monastir (ENIM), University of Monastir, Avenue Ibn El Jazzar 5019, Monastir, Tunisia. [e-mail], [e-mail]. ABSTRACT Multi-point flexible forming (MPF) process is relatively recent flexible techniques [1], instead of the conventional fixed shape die sets, the basic idea in this process, consist to form the sheet metal between a pair of opposed matrices of punch elements, by adjusting the height of the punch elements [2]. Production of many parts with different geometry will be possible, just by using one same device and the need to design and manufacturing of various dies will be avoided that lead to great saving in time and manufacturing cost specially in the field of small batch or single production. The hydroforming process is attractive compared with conventional solid die forming processes, the basic idea consist to suppress one tool of two forming tools (punch or die), which is replaced by hydraulic pressure, only one tool is necessary to define the final shape of formed sheet. The multipoint flexible hydroforming, proposed in this paper, is an original process which combines the hydroforming and the multipoint flexible forming [3], to obtain a synergy of the advantages of both processes. The new process, subject of this work, is a combination of the last described processes that keep the whole flexibility of the basic multipoint flexible forming (with two dies), by using, only at one side, a single multipoint die to perform completely the final part shape, the fluid pressure is applied on the other side of the sheet metal part and substitutes advantageously the second die. Firstly, investigations were carried out by numerical simulation, to quantify, the effect of the most influent parameters on the process performances, and to highlight the ability of this new process, in the production of complex forms, as well as its contribution in quality, placed with regards existing flexible processes. Secondly, to prove the feasibility and to carry out a valuable experimental investigation of the multipoint flexible hydroforming, an experimental prototype was designed and realized, and successful doubly curved shell shape parts were obtained by the new process testing set up. The part profiles and the thickness distribution were in agreement with those obtained by numerical investigation furthermore, numerical investigation for efficient methods to suppress the dimpling phenomenon and edge buckling were confirmed by experimental investigation. From investigations it appears that the parameters attached to the discreet character of the multipoint tool, have an important effect on the quality of the final metal sheet product, such as, the punch elements density, the punch elements extremity curvature radius, the blank and the elastomeric interpolator thicknesses. From simulation results, it emerges essentially, that an adequate setting of parameters can upgrade the thickness distribution, reduce the residual stress and attenuate the dimples. References: [1] Zhong-Yi Cai, Shao-Hui Wanga, Ming-Zhe Li, (2008), Numerical investigation of multi-point forming process for sheet metal: wrinkling, dimpling and spring back, Int J Adv Manuf Technol (2008) 37:927–936. [2] Zhong-Yi Cai, Shao-Hui Wang, Xu-Dong Xu, Ming-Zhe Li (2009), Numerical simulation for the multi-point stretch forming process of sheet metal, journal of materials processing technology 209 (2009) 396–407. [3] N. Selmi, H. Bel hadj salah, Simulation numérique de l’hydroformage à matrice flexible, 7éme journées scientifiques en mécanique et matériaux JSTMM2010, Hammamet 26-27 novembre2010.

• Periodical: Key Engineering Materials (Volumes 554-557)
• Pages: 1290-1297
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.554-557.1290
• Online since: June 2013
• Authors: Selmi Naceur, Bel Hadj Salah Hedi
• Keywords: Complex Forming, Flexibility, Hydroforming, Multipoint, Simulation

References

[1] R. C. Schwarz, J. NARDIELLO,JOHN M. Paparazian, Suppression of dimpling in sheet metal parts formed on discrete tooling, Northrop Grumman Technology Development bethpage, New York,11714-3581, Recent Advances in Experimental Mechanics,2002 Kluwer Academic Publishers,757-768.

DOI: 10.1007/0-306-48410-2_70

[2] Ming-zhe Li, Yuhong Liu, Shizong Su, Guandgquan Li, Multi-point forming: A flexible manufacturing method for a 3-d surface sheet, Journal of Materials Processing Technology 87 (1999) 277–280.

DOI: 10.1016/s0924-0136(98)00364-1

[3] Ming-Zhe Li, Zhong-Yi Cai_, Chun-Guo Liu(2007), Flexible manufacturing of sheet metal parts based on digitized-die, Robotics and Computer-Integrated Manufacturing 23 (2007) 107–115

DOI: 10.1016/j.rcim.2005.09.005

[4] A-M. Yan, I. Klappka, (2008), Spring-back in stretch forming process of aeronautic panel production by finite element simulation, Int J Mater Form (2008) Suppl 1:201–204.

DOI: 10.1007/s12289-008-0026-z

[5] Cai Zhongyi, Li Ming zhe, (2001), Optimum path forming technique for sheet metal and its realization in multi-point forming, Journal of Materials Processing Technology 110 (2001) 136-141.

DOI: 10.1016/s0924-0136(00)00837-2

[6] Se Yun Hwang, Jang Hyun Lee, Yong Sik Yang, Mi Ji Yoo, (2010) Springback adjustment for multi-point forming of thick plates in shipbuilding ,Computer-Aided Design 42 (2010) 1001_1012.

DOI: 10.1016/j.cad.2010.01.005

[7] Q. Zhang, T.A. Dean, Z.R. Wang, (2006a), Numerical simulation of deformation in multi-point sandwich forming, International Journal of Machine Tools & Manufacture 46 (2006) 699–707.

DOI: 10.1016/j.ijmachtools.2005.07.034

[8] Q. Zhang , Z.R. Wang, T.A. Deana, (2007b), Multi-point sandwich forming of a spherical sector with tool-shape compensation, Journal of Materials Processing Technology 194 (2007) 74–80.

DOI: 10.1016/j.jmatprotec.2007.04.002

[9] Q. Zhang _, Z.R. Wang , T.A. Dean, (2008c), The mechanics of multi-point sandwich forming, International Journal of Machine Tools & Manufacture 48 (2008) 1495– 1503.

DOI: 10.1016/j.ijmachtools.2008.04.003

[10] Zhong-Yi Cai, Shao-Hui Wanga, Ming-Zhe Li, (2008), Numerical investigation of multi-point forming process for sheet metal: wrinkling, dimpling and springback, Int J Adv Manuf Technol (2008) 37:927–936.

DOI: 10.1007/s00170-007-1045-5

[11] Zhong-Yi Cai, Shao-Hui Wang, Xu-Dong Xu, Ming-Zhe Li (2009), Numerical simulation for the multi-point stretch forming process of sheet metal, journal of materials processing technology 209 (2009) 396–407.

DOI: 10.1016/j.jmatprotec.2008.02.010

[12] N. Selmi, H. BelHadj Salah, Simulation numérique de l'hydroformage à matrice flexible, 7éme journées scientifiques en mécanique et matériaux JSTMM2010, Hammamet 26-27 novembre2010.

[13] N. Selmi, H. BelHadj Salah, Hydroformage flexible multipoint : Aptitudes aux formes complexes, CMSM2011, Sousse 31 mai-1erJuin 2011.

[14] N. Selmi, H. Bel Hadj Salah, Flexible multipoint hydroforming using metallic sheet medium, Second Tunisian Congress of Mechanics,19 – 21 March 2012, Sousse - Tunisia, Cotume2012.
