Evaluating Material Constitutive Equations for the Simulation of Incremental Sheet Forming Applied to Form Thermoplastic Materials

Abstract:

Incremental Sheet Forming (ISF) is able to produce highly customized products at a reasonable manufacturing cost and it has gain importance in the last years, becoming the focus of interest for many researchers and institutions. Some recent publications have revealed an increasing interest in forming thermoplastic materials. There is a tremendous amount of effort put in developing a model that may describe the equilibrium hysteresis and rate-dependence of thermoplastic materials in ISF. This paper will present a brief review of the most common constitutive equations that are able to model the behaviour of glassy polymers. It will be shown that by using a small number of material parameters defined in the Marlow model, it is possible to accurately predict experimental data collected on samples of PVC subjected to simple uniaxial test performed at room temperature. Additionally, some parts have been formed with ISF in order to verify whether the material is incompressible or not. It can be concluded that Marlow model might be used in future work to model the ISF manufacturing process.

• Periodical: Key Engineering Materials (Volumes 554-557)
• Pages: 1312-1319
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.554-557.1312
• Online since: June 2013
• Authors: Isabel Bagudanch, Alex Elías-Zúñiga, Maria Luisa Garcia-Romeu
• Keywords: Constitutive Equation, Incremental Sheet Forming (ISF), Thermoplastic Materials

References

[1] G. Ambrogio, L. Denapoli, L. Filice, F. Gagliardi, M. Muzzupappa, Application of Incremental Forming process for high customised medical product manufacturing, J. Mat. Proc. Tech. 162-163 (2005) 156-162.

DOI: 10.1016/j.jmatprotec.2005.02.148

[2] J.R. Duflou, B. Lauwers, J. Verbet, F. Gelaude, Y. Tunçkol, Medical application of single point incremental forming: Cranial plate manufacturing, Virtual Modelling and Rapid Manufacturing - Advanced Research in Virtual and Rapid Prototyping. (2005) 161-166.

[3] S. Tanaka, T. Nakamura, K. Hayakawa, H. Nakamura, K. Motomura, Residual stress in sheet metal parts made by incremental forming process. AIP Conference Proceedings. 908 (2007) 775-780.

DOI: 10.1063/1.2740904

[4] V. Oleksik, A. Pascu, C. Deac, R. Fleaca, M. Roman, O. Bologa, The influence of geometrical parameters on the incremental forming process for knee implants analyzed by numerical simulation, AIP Conference Proceedings. 1252 (2010) 1208-1215.

DOI: 10.1063/1.3457520

[5] A. Fiorentino, G.P. Marenda, R. Marzi, E. Ceretti, D.T. Kemmoku, J.V. Lopes da Silva, Rapid prototyping techniques for individualized medical prosthesis manufacturing, Proceedings of the 5th International Conference on Advanced Research and Rapid Prototyping. (2012) 589-594.

DOI: 10.1201/b11341-94

[6] V. Franzen, L. Kwiatkowsky, P.A.F. Martins, A.E. Tekkaya, Single point incremental forming of PVC, J. Mat. Proc. Tech. 209 (2008) 462-469.

DOI: 10.1016/j.jmatprotec.2008.02.013

[7] A.P. Tom, Æ. Engels, H.M. Serge, T.H., Söntjens, Æ. Smit, E. Leon, Time-dependent failure of amorphous polylactides in static loading conditions, J Mater Sci Mater Med. 21 (2010) 89-97.

DOI: 10.1007/s10856-009-3851-9

[8] E. Krempl, K. Ho, An overstress model for solid polymer deformation behavior applied to Nylon 66, ASTM special technical publication. 1357 (2000) 118-137.

DOI: 10.1520/stp15832s

[9] V.S. Le, Modeling of single point incremental forming process for metal and polymeric sheets, PhD thesis (2009).

[10] S. Alkas Yonan, P. Haupt, L. Kwiatkowski, V. Franzen, A. Brosius, E. Tekkaya, A viscoplastic material model based on overstress for the simulation of incremental sheet forming of thermoplastics, 14th International ESAFORM Conference on Material Forming. (2011) 828-833.

DOI: 10.1063/1.3589614

[11] S. Alkas Yonan, P. Haupt, L. Kwiatkowski, V. Franzen, A. Brosius, E. Tekkaya, Three-dimensional formulation and validation of a new viscoplastic material model for the simulation of incremental forming of thermoplastics, 10th International Conference on Technology of Plasticity Aachen. (2011) 973-977.

DOI: 10.1063/1.3589614
