Rapid Manufacturing of Shaped Die and Draw Punch Tools for Presses

Abstract:

Traditionally forming tools for a press are machined with a CNC-machine. This is quite time consuming - calculating tool tracks, selecting cutting tools, cutting blanks, design fixation and finally machining - especially for a small batch of parts. One alternative method is to cut a die and a draw punch tools from a blank sheet and bunching the plates. Clamping plates together is fast and easy to implement by using for example studs and bars with a certain tolerance to ensure alignment. A laser, a water jet or a plasma cutter can be used for cutting plates. Especially the laser and the water jet cutting are precise methods giving a fine surface quality without a need for fine-tuning. The method saves material compared with machining because a die and a punch could be cut at the same time from a blank sheet as compatible pair as well as the needed amount of plates could be estimated depending of the length of a pressed product. University of Oulu, Oulu Southern institute, Future Manufacturing Technology -group has manufactured several forming tools within this technique and found it extremely suitable for experimenting different solutions and options fast. Furthermore, the method is likely to help especially SMEs in their R&D-phase by lowering production costs in a cost-efficiency way.

• Periodical: Key Engineering Materials (Volumes 554-557)
• Pages: 1814-1818
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.554-557.1814
• Online since: June 2013
• Authors: Markku Kananen, Mikko Hietala, Kari Mäntyjärvi
• Keywords: Cost-Efficiency, Forming, Lead-Time, Press, Sheet Metal Forming

References

[1] K. Mäntyjärvi, J.A. Karjalainen, A. Järvenpää and A. Määttä, Roll Forming of Tailored Heat Treated Ultra High Strength Steel Strips, End report of the project, Oulu Southern institute 2007-2011.

[2] D.H. Mueller and H. Mueller, Experiences Using Rapid Prototyping Techniques to Manufacture Sheet Metal Forming Tools, Isata 2000, Dublin, Ireland, 25-27th Sep., 2000.

[3] M. Radovanovic and P. Dašic, Research on surface roughness by laser cut, The Annals of University Dunarea se jos of Galati, Fascicle VIII, 2006, pp.84-88.

[4] J. Kantola and al., Influence of Plasma, Laser and Waterjet Cutting on Fatigue Life of Austenitic-Ferritic Stainless Steel, XVI International Colloquium of Mechanical Fatigue of Metals, Brno, Czech Republic, 24-26th Sep., 2012.

[5] A. Väisänen, K. Mäntyjärvi and J.A. Karjalainen, Bendability of Ultra-High-Strength Steel, International Journal of Key Engineering Materials Vols. 410-411, 2009, pp.611-620.

DOI: 10.4028/www.scientific.net/kem.410-411.611

[6] K. Mäntyjärvi and al., Laser-Assisted Bending, International Journal of Key Engineering Materials Vol. 344, 2007, pp.235-241.

[7] M. Keskitalo and al., Local Laser Heat Treatment of Ultra-High Strength Steel, Proceedings of the 11th NOLAMP Conference in Laser Processing of Materials, August 2007, Lappeenranta, Finland, 2007, pp.536-543.

[8] A. Järvenpää, K. Mäntyjärvi, A. Merklein and al., Mechanical properties of laser heat treated 6 mm thick UHS-steel, Proceedings of the 14th ESAFORM Conference on Material Forming, Belfast Ireland, 26-29th April 2011, Vol. 1353, pp.1319-1324.

[9] J. Kantola, K. Mäntyjärvi K. and J.A. Karjalainen, Laser Assisted Cutting of Abrasion Resistant Steel, Key Engineering Materials Vols. 504-506, 2012, pp.1371-1376.

DOI: 10.4028/www.scientific.net/kem.504-506.1371

[10] Laser cutting, 2012, available at http://en.wikipedia.org/wiki/Laser_cutting, accessed at 30.11.(2012)

[11] Water jet cutting, available at http://en.wikipedia.org/wiki/Water_jet_cutter, accessed at 30.11.(2012)
