Development and Validation Roadmap for In Situ Structural Health Monitoring of ADF Aircraft

Abstract:

In recent times there has been concerted pressure on military organisations worldwide to push for significant reductions in through-life support costs while maintaining and improving aircraft availability and safety. These goals, which on the surface may appear contradictory, can be achieved through the introduction of Structural Health Monitoring (SHM) systems. The paper describes the Australian Defence Science and Technology Organisation (DSTO) roadmap for SHM system development, validation, certification and implementation, in the context of technologies and systems that meet Australian Defence Force (ADF) future requirements. The current approach focuses on wide-area damage detection SHM systems using acousto-ultrasonic techniques.

• Periodical: Key Engineering Materials (Volume 558)
• Pages: 534-545
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.558.534
• Online since: June 2013
• Authors: Steve C. Galea, Nik Rajic
• Keywords: Acousto-Ultrasonic, Condition Based Maintenance, Structural Health Monitoring (SHM)

References

[1] Rajic, N. Development of an Active Smart Patch for Aircraft Repair. Encyclopedia of Structural Health Monitoring, Boller, C., Chang, F., and Fujino, Y., (Eds). John Wiley & Sons Ltd, Chichester, UK. 1867-1880, (2009).

DOI: 10.1002/9780470061626.shm135

[2] Galea S, Rosalie C, Rajic N. Acousto-Ultrasonic In Situ Monitoring of Fatigue Cracking in an Aircraft Wing Skin Specimen. Proceedings of the 8th International Workshop on Structural Health Monitoring, Stanford University, Stanford, CA. 13-15 September, pp.1978-1985, (2011).

[3] Galea S, Rajic N, Davis C, Tsoi N, Rosalie C, Powlesland I. In Situ Structural Health Monitoring Approaches for Military Aircraft Structures. Proceedings of the Third Asia-Pacific Workshop on Structural Health Monitoring, Tokyo, Japan, Nov 30 - Dec 2, (2010).

[4] Rajic N, Rosalie, S C, Tsoi K A. In-situ Monitoring of Fatigue Cracking in a Wing Skin by Means of Acousto-Ultrasonics. DSTO Technical Report in draft.

[5] Boykett R and Walker K F. F-111C Lower Wing Skin Bonded Composite Repair Substantiation Testing. DSTO-TR-0480, Defence Science and Technology Organisation, Australia, Melbourne, (1996).

[6] Baker A A. A proposed Approach for Certification of Bonded Composite Repairs to FlightCritical Airframe Structures. Applied Composite Materials, Vol 18, pp.337-369, (2011).

DOI: 10.1007/s10443-010-9161-z

[7] Baker A A, Rajic N, Davis C. Towards a Practicle Health Monitoring System for Patched Cracks in Aircraft Structure. Composites: Part A, Vol 40A, pp.1340-1352, (2009).

DOI: 10.1016/j.compositesa.2008.09.015

[8] Rajic N., Rosalie, C., Ong, W. and Chiu, W. Simulation of Lamb Wave Scattering for Structural Health Monitoring System Design, Presented at the 6th European Workshop on Structural Health Monitoring, Dresden, Germany, July 3-6, (2012).

DOI: 10.1177/1475921717715302

[9] Tsoi K A, Rajic N. Mechanical Durability of Piezoceramic Transducers for Structural Health Monitoring Applications", Proceedings of the Third Asia-Pacific Workshop on Structural Health Monitoring, Tokyo, Japan, Nov 30 - Dec 2, (2010).

[10] Rajic N, Tsoi K A, Rosalie C. Issues on the Durability of Piezoceramic transducers for in situ SHM using Acousto Ultrasonics. Proceedings of the International Symposium on NDT in Aerospace, Hamburg, Germany, Nov 22-24, (2010).

[11] Davis C, Tejedor S, Grabovac I, Kopczyk J, Nuyens T. High-Strain Fibre Bragg Gratings for Structural Fatigue Testing of Military Aircraft. Photonic Sensors (Article In Press), (2012).

DOI: 10.1007/s13320-012-0066-3

[12] Rajic N, Davis C, Thomson A. Acoustic-wave-mode separation using a distributed Bragg grating sensor. Smart Mater. Struct. Vol. 18, p.125005 (9pp), (2009).

DOI: 10.1088/0964-1726/18/12/125005

[13] Rosalie C, Norman P, Smithard J, Davis C, Rajic N. Optical Fibre Sensing of High Order Lamb Waves for Structural Health Monitoring. Proceedings of the ASME 2012 Conference on Smart Materials, Adaptive Structures & Intelligent Systems SMASIS 2012, Stone Mountain, Georgia, USA. September 19-21, 2012.

DOI: 10.1115/smasis2012-8023
