Structural Modification and Airflow Optimization of Bag-Type Collector Based on Flue-Gas Rich-Lean Separation

Abstract:

With the computational fluid dynamics software FLUENT, three dimensional gas-solid two-phase flow field was simulated and analyzed for HMC-64 pulse-jet cleaned bag-type collector. The simulation data and the actual operating parameters were compared, and the airflow distribution of bag-type collector was comprehensively learned. On the basis of the original analysis, the reconstruction about flue-gas rich-lean separation combining lateral extension at the entrance of bag filter was put forward. The velocity distribution and the mass flow rate of all filter bags were compared. Results showed that through using rich-lean separation combining lateral extension, the airflow distribution of each filter bag was optimized. The integrated flow non-uniform amplitude and the relative root-mean-square value became lower than those of original model. These conclusions about the structural modification and the airflow optimization provide theoretical foundation for further research.

• Periodical: Key Engineering Materials (Volume 561)
• Pages: 553-558
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.561.553
• Online since: July 2013
• Authors: Rong Li, Bing Zhen Zhang, Bin Zhang
• Keywords: Airflow Distribution, Bag-Type Collector, Flue-Gas Rich-Lean Separation, Lateral Extension, Numerical Simulation

References

[1] H. Gao, L.J. Guo: Journal of Xi'an Jiaotong University Vol.34 (2000), p.50

[2] J.Q. Wang, G.F Liu: Petro-chemical Equipment Vol.37 (2008), p.71

[3] G.D. Gao, L.L. He: Coal Mine Machinery Vol.31 (2010), p.38

[4] S.H. Li, K.Y. Wang: Power System Engineering Vol.25 (2009), p.17

[5] Y. Yuang, Y. Yang: Morden mining vol.6 (2009), p.56

[6] A. Subrenat, J. Bellettre: Chemical Engineering Science Vol.58 (2003), p.4965

[7] Theo Schrooten, Ralf Esser and Kristina Knop: ZKG INTERNATIONAL Vol.62 (2009), p.6

[8] H. Zhou, K.F. Cen: Proceedings of the CSEE VOl.23 (2003), p.132

[9] H. Zhou, L. L. Du: Proceedings of the CSEE Vol.23 (2003), p.178

[10] S. L. Yuan: Xi'an University of Architecture and Technology (2006).
