Analysis of Thermal Field of Gear Driving with Meshed Medium Belt

Abstract:

Solid models of the involute gear, the gear with meshed medium belt and the medium belt were built with the PROE software. Then the steady-sate temperature field of the solid model was analyzed with ANSYS software. The result showed that the body temperature distribution on the tooth face was not effected by the medium belt. Different duty parameters were selected to analyze the highest temperature of the medium belt. So theory basis for choose of the medium belt and the duty parameters was provided.
