Research on the Self-Cleaning Sole Cleaner

Abstract:

The self-cleaning sole cleaner designed in this paper is a kind of cleaning device widely used in large public places. It possesses functions such as washing, wiping, drying and self cleaning, and so can thoroughly clean sole. It is chiefly composed of pressure washing unit and self-cleaning wiping unit. The device washes the sand and mud adhered to sole by the pressure water coming out of the pressure cleaning head at first, and then wipes off the sole sewage by the wiping unit, finally dries sole. Main advantages of the cleaner are concluded to simple structure, good cleaning effect, energy saving, and environmental protection by adopting the technologies of water level automatic keep and sewage dispose.

• Periodical: Key Engineering Materials (Volume 561)
• Pages: 581-584
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.561.581
• Online since: July 2013
• Authors: Zhan Guo Zhang, Li Xia Sun, Xiao Yong Liu, Jian Yong Li, Xiang Yan Lv
• Keywords: Cleaning Head, Sole Cleaner, Wiping Unit

References

[1] G.Y. Mei: Electrical Appliances, (1998) No.2, pp.2-3.

[2] J.J. Guo, Z.Y. Xu, J. Wang and J. Ding: Industrial Water & Wastewater, Vol. 35 (2004) No.4, pp.49-51.

[3] E. Tobey, U.S. Patent0, 302,200, (2008).

[4] F. Liu, K. Yu, X.J. Li, Z.X. Li and D.X. Li: Advanced Display, (2007) No.10, pp.54-56.
