Finite Element Analysis and Research of Beam Based on Workbench

Abstract:

According to XQ2010 planomiller, three-dimensional physical model is built by using Solidworks software. With the model imported into workbench, the static and dynamic state of beam is analysed. The features of stress and deformation are observed under ultimate load. Its six modes of vibration are extracted for confirming the characteristic of beam in modal analysis.
