Structural Health Monitoring under Varying Environmental Conditions Using Wavelets

Abstract:

A novel structural health monitoring system to detect damages in structures under varying operational and environmental conditions is presented in this paper. A noncontact, full-field measurement using a high speed camera offers a convenient and less expensive measurement procedure, enabling the measuring of responses in elevated temperatures and in conditions where contact sensors are unable to be used. In this paper, a combination of Decay lines of the Wavelet Transform Modulus Maxima (WTMM) and Holder Exponent (HE) are used to distinguish changes on the time response of a vibrating structure due to the operational and environmental variations to changes due to the presence of damage, thus minimising the possibility of false alarm. The proposed methodology is demonstrated using a 3-DOF system under conditions of varying and constant temperatures with the presence of damage, as well as using an experimental setup of a cantilever beam under intact and damaged conditions.

• Periodical: Key Engineering Materials (Volumes 569-570)
• Pages: 1218-1225
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.569-570.1218
• Online since: July 2013
• Authors: Andreas Tjirkallis, Andreas Kyprianou, George Vessiaris
• Keywords: Digital Video Imaging, Holder Exponent, Structural Health Monitoring (SHM), WTMM

References

[1] Doebling, S.W., Farrar, C.R., Prime, M.B., Shevitz, D.W., Damage identification and health monitoring of structural and mechanical systems from changes in their vibration characteristics: Literature review, Report No. LA-13070-MS, Los Alamos National Laboratory, (1996).

DOI: 10.2172/249299

[2] Huang Lu, Refined Boundary Effect Evaluation Method for on-site damage inspection of structures, PhD Thesis, University of Missouri-Columbia, (2005).

[3] Cornwell P., Farrar C.R., Doebling S.W., Sohn H., Environmental variability of modal properties, Experimental Techniques, 1999, 45–48.

DOI: 10.1111/j.1747-1567.1999.tb01320.x

[4] Sohn H., Effects of environmental and operational variability on structural health monitoring, Philosophical Transactions of the Royal Society A 365(1851) (2003) 539–560.

DOI: 10.1098/rsta.2006.1935

[5] Gopalakrishnan S., et al., Computational Techniques for Structural Health Monitoring, Springer (2011).

[6] Peng Z. K. et al., Singularity analysis of the vibration signals by means of wavelet modulus maximal method. Mechanical Systems and Signal Processing 21 (2007), pp.780-794.

DOI: 10.1016/j.ymssp.2005.12.005

[7] Douka et al., Crack identification in beams using wavelet analysis, Douka E., Loutridis, S. and Trochidis, A. International Journal of Solids and Structures (2003), 40, 3557-3569.

DOI: 10.1016/s0020-7683(03)00147-1

[8] Gentile and Messina. On the continuous wavelet transforms applied to discrete vibrational data for detecting open cracks in damaged beams. International Journal of Solids and Structures (2003), 40, 295-315.

DOI: 10.1016/s0020-7683(02)00548-6

[9] Mallat S. A Wavelet Tour of Signal Processing, 2nd ed., London, UK. Academic Press, (1999).

[10] Hasse and Widjakusuma. Damage identification based on ridges and maxima lines of wavelet transform, Int. Journal of Engineering Science (2003), 41, 1423-1443.

DOI: 10.1016/s0020-7225(03)00026-0

[11] Robertson A. N et al., Singularity Detection for Structural Health Monitoring Using Holder Exponents, Mechanical Systems and Signal Processing (2003), 17(6), 1163-1184.

DOI: 10.1006/mssp.2002.1569

[12] Mallat S. and Hwang W.L., Singularity detection and processing with wavelets, IEEE Transactions on Information Theory 38, 617–643, (1992).

DOI: 10.1109/18.119727

[13] Harvey D. Y and Todd M. D., Cointegration as a data normalization tool for structural health monitoring applications. HMSBS 2012, Proc. Of SPIE Vol. 8348.

DOI: 10.1117/12.915226

[14] Patsias S., Extraction of Dynamic Characteristics from Vibrating Structures using Image Sequences, PhD Thesis, University of Sheffield, November (2000).
