Changes in the Dynamic Behaviour of Carbon Fibre Reinforced Polymer Elements with Increasing Damage

Abstract:

This paper deals with effects of damage on Carbon FRP (CFRP) elements subjected both to defects and micro-cracking due to static tensile loading through an investigation of CFRP elements under natural vibration tests. The correlation between the response and frequency decrease due to damage for cross section reduction of CFRP cantilever beam elements has been analysed. Successively, the response of CFRP subjected to different values of tensile force has been investigated; experimental frequency values are compared with theoretical values and discussed.

• Periodical: Key Engineering Materials (Volumes 569-570)
• Pages: 56-63
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.569-570.56
• Online since: July 2013
• Authors: Roberto Capozucca, Vanessa Maccioni
• Keywords: Carbon Fiber Reinforced Polymer/Plastic (CFRP), Damage, Static Tensile Test, Vibration Test

References

[1] R. Capozucca, M.N. Cerri, Static and dynamic behaviour of RC beam model strengthened by CFRP sheets, Construction and Building Materials 16 (2002) 91-99.

DOI: 10.1016/s0950-0618(01)00036-8

[2] R. Capozucca, Static and dynamic response of damaged RC beams strengthened with NSM CFRP rods, Composite Structures 91 (2009) 237-248.

DOI: 10.1016/j.compstruct.2009.05.003

[3] B. Bonfiglioli, G. Pascale, Dynamic behaviour and modelling of RC beams retrofitted with CFRP sheets, CISM courses and lectures no. 471, Udine. Springer Wien New York (2003) 47-57.

DOI: 10.1007/978-3-7091-2536-6_4

[4] B. Baghiee, M.R. Esfahani, K. Moslem, Studies on damage and FRP strengthening of reinforced concrete beams by vibration monitoring, Engineering Structures 31 (2009) 875-893.

DOI: 10.1016/j.engstruct.2008.12.009

[5] R. Capozucca, Assessment of CFRP strengthened RC beams through dynamic tests, J. Composite B: Engineering 46 (2013) 69-80.

DOI: 10.1016/j.compositesb.2012.10.010

[6] C. Caleb White, H.C.H. Li, B. Whittingham, I. Herszberg, A.P. Mouritz, Damage detection in repairs using frequency response technique, Composite Structures, 87 (2009) 175-180.

DOI: 10.1016/j.compstruct.2008.05.010

[7] B. Whittingham, H.C.H. Li, I. Herszberg, W.K. Chiu, Disbond detection in adhesively bonded composite structures using vibration signature, Composite Structures, 75 (2006) 351-363.

DOI: 10.1016/j.compstruct.2006.04.055

[8] S.S. Kersler, S.M. Spearing, M.J. Atalla, C.E.S. Cesnik , C. Sontis, Damage detection in composite materials using frequency response methods, Composites: Part B, 33 (2002) 87-95.

DOI: 10.1016/s1359-8368(01)00050-6

[9] E.V.V. Ramanamurthy, K. Chandrasekaran, Vibration analysis on a composite beam to identify damage and damage severity using finite element method, IJEST, 3(7), (2011), 5865-5888.

[10] P. Cawley, R.D. Adams, The location of defects in structures from measurements of natural frequencies, J. Strain Anal. Engrg. Des. 14 (1979) 49–57.

DOI: 10.1243/03093247v142049

[11] O.S. Salawu, Detection of structural damage through changes in frequency: a review, Engineering Structures 19 (1997) 718-723.

DOI: 10.1016/s0141-0296(96)00149-6

[12] J.R. Casas, A.C. Aparicio, Structural damage identification from dynamic–test data, J. Structural Engineering 120 (1994) 2437-2450.

DOI: 10.1061/(asce)0733-9445(1994)120:8(2437)

[13] M.N. Cerri, F. Vestroni, Detection of damage in beams subjected to diffused cracking, J. Sound and Vibration 234 (2) (2000) 259-276.

DOI: 10.1006/jsvi.1999.2887

[14] M.M.F. Yuen, A numerical study of the eigenparameters of a damage cantilever, J. Sound Vib. 109(3) (1985) 301-310.

[15] W.M. Ostachowics, M. Krawczuk, Analysis of the effect of cracks on the natural frequencies of a cantilever beams, J. Sound Vib. 150 (1991) 191-201.

DOI: 10.1016/0022-460x(91)90615-q

[16] Y. Narkis, Identification of crack location in vibrating simply supported beams, J. Sound Vib. 172 (1994) 549-558.

DOI: 10.1006/jsvi.1994.1195

[17] S. Christides, A.D.S. Barr, One dimensional theory of cracked Bernoulli-Euler beams, Int. J. Mech. Sci. 26 (1984) 639-648.

DOI: 10.1016/0020-7403(84)90017-1

[18] M.H.H. Shen, C. Pierre, Free vibration of beams with a single-edge crack, J. Sound Vib. 170 (1994) 237-259.

DOI: 10.1006/jsvi.1994.1058

[19] X.F. Yang, A.S.J. Swamidas and R. Seshadri, Crack identification in vibrating beams using energy method, J. Sound Vib. 224(2) (2001) 339-357.

DOI: 10.1006/jsvi.2000.3498

[20] G.B. Warburton, The dynamical behaviour of structures, Pergamon Press, Oxford, (1964).

[21] ASTM D 3039/D 3039 M – 08, Standard Test Method for Tensile Properties of Polymer Matrix Composite Materials, American Standard of Testing and Materials (2008).
