A 5-DOF Combined Robot Platform for Automatic 3D Measurement

Abstract:

This paper describes the reconstruction process of a 3P2R type combined robot platform on the basis of a 2-axis linearly moving worktable. An additive 3-DOF manipulator installed above the worktable has one prismatic and two revolute joints by using a novel integrated ball screw and spline axis. The control system of the platform is composed of a 4-axis motion control card and a PLC. Meanwhile, this paper deduces the kinematic equations of this special combined platform for measurement. The 3P2R type platform could be used to measure 3D contour of small work piece automatically.

• Periodical: Key Engineering Materials (Volumes 579-580)
• Pages: 641-644
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.579-580.641
• Online since: September 2013
• Authors: Jun Qian, Hua Bing Zhu, Shu Wang Wang, Yi Shan Zeng
• Keywords: Controller, Industrial Robot, Manipulator, Measurement

References

[1] X.C. Zhang: Reverse Modeling Technique and Product Innovation Design. (Peking University Press, China 2009). (In Chinese).

[2] A. Li, W. Wang and D. Wu: Proc. IEEE International Conference on Robotics and Biomimetics (Guilin, China, December 19-23, 2009). pp.1361-1364.

[3] H. Makino and N. Furuya: Robotic Assembly, 1985, pp.13-26.

[4] J. Hu and T. Zhang: Machine Tool and Hydraulics, Vol. 39 (2011), No. 21, pp.28-31. (In Chinese).

[5] Information on http: /www. googoltech. com. cn.

[6] Information on http: /www. automation. siemens. com.

[7] M.W. Spong, S. Hutchinson and M. Vidyasagar: Robot Modeling and Control (John Wiley & Sons, USA 2005), pp.65-102.
