Detection of Surface Damage after Grinding of Large Case–Hardened Bearing Rings

Abstract:

This paper deals with detection of surface damage after grinding of bearing rings made of case hardened steel. Micromagnetic technique based on Barkhausen noise is adopted for monitoring of surface integrity during grinding rings of large diameter (1500 mm). Except micromagnetic testing, investigation of surface integrity is also expressed in such parameters as structure alterations, residual stresses measured via X - ray technique and microhardness measurement. It was found that Barkhausen noise technique enables reliable detection of surface integrity and damage induced by dry grinding and insufficient coolant supply can be easily distinguished.

• Periodical: Key Engineering Materials (Volume 581)
• Pages: 205-210
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.581.205
• Online since: October 2013
• Authors: Maria Čilliková, Miroslav Neslušan, Kamil Kolařík, Marián Mičúch
• Keywords: Barkhausen Noise, Bearings, Grinding Damage

References

[1] Barkhausen, H.: Phys. Zeitschrift 20, 201 (1919).

[2] Altpeter, I. - W. Theiner, W. - R. Becker, R.: Eigenspannungsmessung an stal deer Güte 22 NiMoCr 37 mit magnetischen und magnetoelastischen Prüfverfahren, 4th Intern. Conf. on NDE in Nuclear Industry, Lindau1981.

[3] Abuku, S. – Cullity, R.D.: A Magnetic Method for the Determination of residual Stress, Exp. Mech. 11, (1971).

[4] Theiner, W. - Höller, P.: Magnetische Verfahren zur Spannungsermittlug, HTM – Beiheft Carl Hanser Verlag (1982).

[5] Moorthy, V. et all.: Evaluation of heat treatment and deformation induced changes in material properties in gear steels using magnetic Barkhausen noise analysis, ICBN 03.

[6] Brinksmeier, E. - Heinzel, C. – Wittman, M.: Friction, cooling and lubrication in Grinding, CIRP Vol. 48/2/199.

DOI: 10.1016/s0007-8506(07)63236-3
