Simulation of Grinding Process of Polycrystalline Superhard Materials

Abstract:

The results of investigation in order to increase the efficiency of using diamond-abrasive and edge tool made of superhard materials (SHM) on the basis of 3D methodology of complex research of the interrelated processes of their manufacturing and operation are presented. Creation of 3D simulation methodology of processes of sintering of abrasive-diamond tools and processes of grinding of edge SHM tools with their application allows us to increase considerably the reliability of obtained results, to reduce the extent of experimental studies for determination of optimum conditions for grinding and to develop new technologies, tools and equipment. The scientific hypothesis about the expediency of using diamond powders with thick metal coatings in diamond-abrasive tools on metal bonds are proposed and proved on the basis of theoretical research. The research results are implemented as a number of grinding techniques with controllable cutting relief of the wheels and devices which realize them. Using the results of the research makes it possible to increase the reliability of the edged tool made of SHM as far back as at the stage of its sharpening.

• Periodical: Key Engineering Materials (Volume 581)
• Pages: 217-223
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.581.217
• Online since: October 2013
• Authors: Anatoly I. Grabchenko, Vladimir A. Fedorovich, Ivan Pyzhov, Valery Fadeev, Eugene Babenko, Vitaly Klimenko
• Keywords: Controllable Grinding Process, Deflected Mode, Diamond Grinding Wheel, Finite Element Method (FEM), Metal Bond, Superhard Materials

References

[1] M.J. Jackson, N. Barlow, et. al., Computer Aided Design of High-Performance Grinding Tools /Proceedings of the Institution of Mechanical Engineers (London), Part B /Journal of Engineering Manufacture 215, 2001, 583-588.

DOI: 10.1243/0954405011518395

[2] Sohne J (2003) Beitrag zur Simulation zerspanungstechnologischer Vorgange mit Hilfe der Finite-Element-Methode. Uni- versitat Karlsruhe, Karlsruhe, p.162.

[3] Guo YB, Liu CR (2002) 3D FEA modeling of hard turning. J. Manuf Sci Eng Trans ASME 124: 189–199.

[4] Fischer C (2007) Runtime and Accuracy Issues in Three Dimensional Finite Element Simulation of Machining Proceed- ings of the 10th CIRP International Workshop on Modeling of Machining Operations. 45–50.

DOI: 10.1504/ijmmm.2009.026925

[5] Rizzutti S, Umbrello D, M'Saoubi R, Outeiro JC (2007) Modelling and Validation of Tool Wear During Hard Machining of AISI H13 Tool Steel. Proceedings of the 10th CIRP International Workshop on Modeling of Machining Operations. 293–300.

DOI: 10.1063/1.2740966

[6] Heisel U, Krivoruchko DV, Zaloha VA et al. (2007) Cause Analysis of Errors in FE Prediction Orthogonal Cutting Performance, Proceedings of the 10th CIRP International Workshop on Modeling of Machining Operations, Calabria, p.141–148.

[7] Mamalis AG, Grabchenko AI, Fedorovich VA, Kundrak J (2009) Methodology of 3D simulation of processes in technology of diamond-composite materials. Int J Adv Manuf Technol 43: 1235–1250.

DOI: 10.1007/s00170-008-1802-0

[8] Novikov N.V., Maistrenko A.L., Kulakovskiy V.N. (1993) Fracture Strength of Superhard Composite Materials. Book, Kiev: Scientific Idea, 220 p.

[9] Grabchenko AI, Fedorovich VA, Obrazkov BV (2004) Role of Diamond Concentration in Grinding Wheel When Grinding Polycrystals of Superhard Materials. Superhard Materials 1: 49-52.

DOI: 10.20998/2078-7405.2020.93.04

[10] Fedorovich VA (2002) Elaboration of scientific fundamentals and methods of practical realization of adaptability control at diamond grinding of superhard materials: Thesis, Doct. Techn. Sc.: 05. 03. 01. Kharkov, 466 p.

[11] Mishnaevskiy LL (1982) Wear of grinding wheels. Book. Kiev: Scientific Idea, 192 p.

[12] Epifanov VI, Pesina AYa, Zykov LV (1984) Technology of treatment of diamond into cut diamond. Book, Moscow: Higher School, 319 p.

[13] Kozakova NV, Fedorovich VA (2006).

[14] Ostroverkh EV (1996) Thermal effects and surface layer quality at diamond grinding of superhard materials: Abstract of PhD thesis. Kiev Polytechnic Institute, 17 p.

[15] Novikov NV, Primak LP et al (1981) Investigation of Fatigue Cracks Propagation in Synthetic Diamond Monocrystals. Acad Sci USSR 256: 1122-1126.

[16] Novikov NV, Devin LN (2002).
