Fabrication of Nanostructured Zinc Oxide Films on Plastic Substrates by Pyrolysis Method and their Application to Dye-Sensitized Solar Cells

Abstract:

t has been attempted to utilize plastic substrates for electrodes, instead of conventional glass substrates, to fabricate flexible, lightweight, and low-cost dye-sensitized solar cells (DSSCs). We examined a pyrolysis method by which preformed layered hydroxide zinc acetate (LHZA: Zn₅(OH)₈(CH₃COO)₂·2H₂O) films were converted into ZnO films at temperatures below 120 oC. Since the pyrolyzed films still contained zinc acetate compounds, they were immersed in hot water aiming at removing such the impurities. This hot water treatment influenced the film morphology to a large extent. The energy conversion efficiency of 3.41% was obtained for the cell using an N719/ZnO electrode fabricated on an indium tin oxide-coated polyethylene naphthalate (ITO-PEN) substrate through the present pyrolysis method.
