Experiment Study on Micro-Seam in Electrochemical Machining

Abstract:

In this study, we firstly developed a numerical electrochemical micro-machining (EMM) setup. Furthermore, the effects of five vital process parameters, applied voltage, electrolyte type, electrode shape and diameter, electrode feed rate on micro-seams machining accuracy and process stability were evaluated. The experimental results show that: Wire electrodes machining accuracy is higher than that of sheet electrode. With the wire electrodes diameter decreased from 0.2mm to 0.06mm, micro-seam width is reduced by 36.55%. With the wire electrode feed rate increased from 0.2mm/min to 0.6mmm/min, micro-seam width is reduced by 44.2%. Sheet electrodes machining stability is better than that of wire electrode. The number of machining stability of sheet electrode is 25% higher than that of wire electrode in the condition of 8V applied voltage.

You might also be interested in these eBooks

Progress in Functional Manufacturing Technologies III

View Preview

Info:

Periodical:

Key Engineering Materials (Volume 584)

Pages:

15-19

DOI:

https://doi.org/10.4028/www.scientific.net/KEM.584.15

Citation:

Cite this paper

Online since:

September 2013

Authors:

Zhi Yong Li, Pei Yu Dong, Yi Gang Wang

Keywords:

Electrochemical Micro-Micro-Seam, Machining Precision, Micro-Seam Width, Stability

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

References

[1] Liu Jin-chun, Bai Ji-cheng, Guo Yong-feng. Special processing[M]. Bei Jing: China Machine Press, (2008).

Google Scholar

[2] Xu Hui-yu, Zhu Di, Shi Xian-chuan. Research on electrochemical micro-machining on its system[J]. Sensor technology. 2005, 24(7): 7-9.

Google Scholar

[3] Zhu Di, Wang Ming-huan, Ming Ping-mei. Micro electrochemical machining technology[ J]. Nanotechnology and precision engineering. 2005, 3(2): 151-155.

Google Scholar

[4] Xu Hui-yu, Zhu Di, Zhang Chao-yang. Study on precision electrolytic machining of micro multi-micro-seams. China Mechanical Engineering. 2007, 18(7): 833-837.

Google Scholar

[5] Zhu Di, Wang K, Qu N S. Micro Wire Electrochemical cutting by using In Situ Fabricated Wire Electrode[J]. Annals o f the CIRP, 2007, 56(1): 241-244.

DOI: 10.1016/j.cirp.2007.05.057

Google Scholar

[6] Wang Shao-hua, Zhu Di, Qu Ning-song, Wang Kun. Study on micro micro-seam structure of electrolytic machining[J]. China Mechanical Engineering. 2009, 20(8): 965-969.

Google Scholar

[7] Liu Yong, Zhu Di, Zeng Yong-bin, Huang Shao-fu, Yu Hong-bing, Liu Yong et al. Chinese Journal of Aeronautics 23(2010): 578-584.

Google Scholar
