New Focus on Gearbox Condition Monitoring for Failure Prevention Technology

Abstract:

Condition monitoring is a tool for detection of faults and failure prevention. Fault andfailure are regarded as inevitable during the machine operation as the process of wear and theprocess of degradation. The question is, if one can influence the wear and degradation process,using condition monitoring. The paper will present technology which demonstrates that the use ofthe proper method can influence the wear and machine degradation process, using proper conditionmonitoring techniques and knowing scenarios of wear and degradation process. In the discussionpresented in the paper as a prerequisite has been taken that machinery works in severe dustyenvironment and varying operation conditions. It has been pointed that degradation process is notjust simply development of one fault. Most research for developing technology for conditionmonitoring is concentrated on one fault development. If one considers condition monitoring for acrack and brakeage of a tooth in gearbox, one should take in consideration that tooth crack andbrakeage is the result of several events, like rolling elements bearing frictional wear, which causesecondary misalignment of shaft and gears. The frictional wear is caused by dust particles whichget into oil from the environment in which a gearbox is operating. To avoid an influence ofcontaminated oil, contamination proactive technology should be used for the assessment of thedegree of contamination and the decision on oil purification or change should be taken. The wholeprocess connected with a gearbox condition change (wear and degradation process) shall bedescribed in the paper. The oil purification or its replacement extends the live of gearboxes butlong live of a gearbox, even with very little contamination causes some frictional wear of bearingsand finally secondary misalignment. To avoid further development of degradation process propertechnology should be used. There is a need to measure the degree of misalignment and makedecision on bearings replacement, in order to avoid further gearbox degradation, like teeth scuffingwhich may leads to crack initiation.

• Periodical: Key Engineering Materials (Volume 588)
• Pages: 184-191
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.588.184
• Online since: October 2013
• Authors: Walter Bartelmus
• Keywords: Condition Monitoring, Failure, Gearbox, Prevention, Proactive, Scenario

References

[1] Neville W. Sachs, P.E. Practical plant failure analysis. Taylor & Francis (2007)

[2] Hatangadi A. A. Plant and machinery failure prevention McGraw-Hill (2005)

[3] Gridkhor P. Scheffer C. Practical machinery vibration analysis and predictive maintenance. Elsevier (2004)

[4] Bartelmus W.: Condition monitoring of open cast mining machinery. Oficyna Wydawnicza Politechniki Wrocławskiej Wrocław (2006)

[5] Bartelmus W.: Influence of design, production technology, operation and change of condition factors on gearbox vibration diagnostic signals. Proceedings, Resent Developments in Acoustic, Noise and Vibration. The Sixteenth International Congress on Sound and Vibration Kraków, Poland, 5 – 9 July (2009)

[6] Bartelmus W. Zimroz R.: Vibration spectra characteristics frequencies for condition monitoring of mine machinery compound and complex gearboxes. Scientific Papers of the Institute of Mining of the Wroclaw University of Technology, Mining and geology XVI 2011 Wroclaw pp.17-34

[7] Bartelmus W.: Fundamentals for condition monitoring and diagnostics for driving bucket wheel system with overload mechanism of bucket wheel excavator Scientific Papers of the Institute of Mining of the Wroclaw University of Technology, Mining and. and geology XVI 2011 Wroclaw p.5 – 16

DOI: 10.5593/sgem2015/b13/s3.011

[8] Bartelmus W.: Root cause and vibration signal analysis for gearbox condition monitoring, Insight Vol.50 No4 April (2008)

DOI: 10.1784/insi.2008.50.4.195

[9] Bartelmus W.: Vibration condition monitoring of gearboxes. Machine Vibration 1992 nr1s.178-189

[10] Bartelmus W. Zimroz R.: Vibration condition monitoring of planetary gearbox under varying external load. Mechanical Systems and Signal Processing 23 (2009) 246-257.

DOI: 10.1016/j.ymssp.2008.03.016

[11] Bartelmus W. Zimroz R.: A new feature for monitoring the condition of gearboxes in nonstationary operation conditions. Mechanical Systems and Signal Processing 23 (2009) 1528-1534

DOI: 10.1016/j.ymssp.2009.01.014

[12] Bartelmus W. Chaari F. Zimroz R. Haddar M.: Modelling of gearbox dynamics under time varying non-stationary operation for distributed fault detection and diagnosis European Journal of Mechanics - A/Solids 29 (2010) 637-646

DOI: 10.1016/j.euromechsol.2010.03.002

[13] Bartelmus W. Zimroz R.: Gearbox condition degradation models. Proceedings of Conference on Condition Monitoring and Machine Failure Prevention Technology. Dublin, Ireland, 22-25 June (2009)

[14] Bartelmus W.: Gearbox damage process. Journal of Physics. Conference Series. [electronic document] 2011, Vol. 305, nr 1, 9p. 9th International Conference on Damage Assessment of Structures, DAMAS 2011, Oxford, UK, 11-13 July 2011.

DOI: 10.1088/1742-6596/305/1/012029

[15] Bartelmus W.: Secondary misalignment as the main cause of gearbox failure International Conference on Condition Monitoring, 12-14 June 2012, London, United Kingdom

[16] Morales-Espejel G.E.: Understanding and preventing surface distress. Gear Solutions, July 2012 29- 38pp.

[17] Wowk V. Machine Vibration; Alignment McGraw-Hill (2000)

[18] Bartelmus W., Zimroz R.,The gearbox vibration load susceptibility as the measure of its condition – approaches and procedures for diagnostic relation discovery. International Conference on Condition Monitoring, June 2011, Cardiff , United Kingdom

[19] Alban L. E. 1985 Systematic analysis of gear failures, ASM, ISBN 0-87170-200-2. Amarican Society for Metals

[20] Premature Bearing Failures in Industrial Gearboxes - NREL www.nrel.gov/.../12_premature_bearing_failures.pdf K Stadler Premature bearing failures in industrial gearboxes. Lagerfrühausfälle in Industriegetrieben. Kenred Stadler°. Arno Stubenrauch*. SKF GmbH ...

DOI: 10.1520/stp162320190054

[21] An Introduction to Modern Vehicle Design - Strona 503 - Wynik z Google Books books.google.pl/books?isbn=0750650443 - Julian Happian-Smith - 2001 – Design Failure. prevention. –. The. role. of. endurance. and. durability. studies. in. the. design. and. manufacture. of. reliable. vehicles. F.L. Jones, BSc, PhD, MIM, CEng, ...
