Working Fluid Inventory Effect on Heat Transfer Performance of a Grooved Micro Heat Pipe

Abstract:

As a highly efficient heat transfer component, a micro heat pipe (MHP) has been widely applied to the situations with high heat flux concentration. However, a MHPs heat transfer performance is affected by many factors, among which, working fluid inventory has great influence on the security, reliability and frost resistance of its heat transfer performance. In order to determine the appropriate working fluid inventory for grooved MHPs, this paper first analyzed the working principle, major heat transfer limits and heat flux distribution law of grooved MHPs in electronic chips with high heat flux concentration, then established a mathematic model for the working fluid inventory in grooved MHPs. Finally, with distilled water being the working fluid, a series of experimental investigations were conducted at different temperatures to test the heat transfer performances of grooved MHPs, which were perfused with different inventories and with different adiabatic section lengths. The experimental results show that when the value of α is roughly within 0.40±0.05, a grooved MHP can acquire its best heat transfer performance, and the working fluid inventory can be determined by the proposed mathematic model. Therefore this study solves the complicated problem of determining appropriate working fluid inventory for grooved MHPs.

• Periodical: Key Engineering Materials (Volumes 589-590)
• Pages: 559-564
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.589-590.559
• Online since: October 2013
• Authors: Xi Bing Li, Yun Shi Ma, Xun Wang, Ming Li
• Keywords: Grooved Micro Heat Pipe, Heat Transfer Performance, Mathematics Model, Working Fluid Inventory

References

[1] D.K. Chen: Chinese Journal of Low Temperature Physics Vol. 27 (2005), pp.255-262.

[2] A.I. Uddin, C.M. Feroz: Heat Mass Transfer, Vol. 46 (2009), pp.113-118.

[3] W. Srimuang, S. Rittidech, B. Bubphachot: Journal of Mechanical Science and Technology, Vol. 23 (2009), pp.2548-2554.

DOI: 10.1007/s12206-009-0703-y

[4] J.H. Wu, Y. Tang, L.S. Lu: Journal of Central South University of Technology, Vol. 18 (2011), pp.2170-2175.

[5] Y.C. Chiang, J.J. Chieh, C.C. Ho: Nanoscale Research Letters, Vol. 7 (2012), pp.322-327.

[6] Z.C. Liu, D.X. Gai, W. Liu: Journal of Engineering Thermophysics, Vol. 31 (2010), pp.487-490.

[7] X.B. Li, J.H. Guo, S.G. Wang, et al: Chinese Journal of Vacuum Science and Technology, Vol. 31 (2011), pp.187-193.

[8] Z.Q. Long, P. Zhang: Ciese Journal, Vol. 63 (2012), pp.69-74.

[9] X.B. Li, Z.M. SHI, S.G. Wang, et al: Key Engineering Materials, Vol. 499 (2012), pp.21-26.
