Design and Development of Tracking System for Mines Detector Robot

Abstract:

This paper presents the design and development of tracking system for the mines detector robot. The scope for the tracking system covers two important tasks: 1. Design of optimum tracking path to cover maximum scanning area of an enclosed field, and 2. Obstacles avoidance system to be able avoid the various types of obstacles during the scanning process. The tracking algorithms were designed and simulated using Webots simulation software. Upon successful simulation where all design objectives have been achieved, the algorithms were programmed in microcontroller to implement the tracking system on the mines detector robot. Experimental test rig for the robot was a flat surface, enclosed 3m x 3m area where several obstacles of different sizes and shapes were randomly placed. Several metal samples representing the metal detonator of minefield were also placed to test the sensing system of the robot. Infra-red (IR) sensors were used for the system to detect the obstacles and also to detect the end-path boundary of a routine scanning cycle. While simulation test results have shown achieved design objectives, experimental results shown 90% achievement and limitation on evading big size of circle-type obstacle.

• Periodical: Key Engineering Materials (Volumes 594-595)
• Pages: 919-923
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.594-595.919
• Online since: December 2013
• Authors: Ahamad Zaidi Ahmad Firdaus, Ng Shao Liang, Mohd Bin Sulaiman Hafis, Mohd Jamir Mohd Ridzuan, Nur Hidayah Ahmad Zaidi
• Keywords: Mines Detector Robot, Obstacles Avoidance System, Tracking Path, Tracking System

References

[1] Land mine, Available from: http: /en. wikipedia. org/wiki/Land_mine, 25th May (2013).

[2] Nyein Chann. (2006). Mine Detection and Marking Robot. Department of Mechanical Engineering, National University of Singapore.

[3] Anuar, A., Yussof, S., Said, I., & Chuan, J. T. T. (2003). The Development of an Autonomous Personal Mobile Robot System for Land Mines Detection on Uneven Terrain: An Experience.

[4] Aoyama, H., Ishikawa, K., Seki, J., Okamura, M., Ishimura, S., & Satsumi, Y. (2007). Development of mine detection robot system.

DOI: 10.5772/5693

[5] Zubair, M., & Choudhry, M. A. (2010). Land mine detecting robot capable of path planning.

DOI: 10.1109/wcse.2010.34

[6] Gonzalez de Santos*, P., Garcia, E., Estremera, J., & Armada, M. A. (2005). DYLEMA: Using walking robots for landmine detection and location.

DOI: 10.1080/00207720500119197
