Evaluation of Thermal Stresses in Sandwich Panels with Chiral Cellular Cores

Abstract:

Sandwich panels are important components of advanced structures used in aerospace, automotive, railway, civil engineering etc. They are subjected to high and repeated variations of temperature which induce additional stresses as the core and the face sheets are from different materials having different coefficients of thermal expansion and moduli of elasticity. Therefore it is important to evaluate both mechanical and thermal stresses. In the literature one can find thermo-mechanical analyses of sandwich panels with metallic or composite face sheets and having a honeycomb or compact core made from polyurethane foam. In this paper was analysed a plane sandwich panel made from a cellular rigid polyurethane core, having a chiral configuration and auxetic properties (negative Poissons ratio) exposed to a stationary temperature field with a linear variation from +25 °C on one sheet to-50 °C on the opposite sheet. Two boundary conditions were considered in the thermo-mechanical evaluation: the free panel and the panel simply supported around the edges.

• Periodical: Key Engineering Materials (Volume 601)
• Pages: 242-245
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.601.242
• Online since: March 2014
• Authors: Stefan Sorohan, Dan Mihai Constantinescu, Marin Sandu, Adriana Sandu
• Keywords: Auxetic Sandwich Panel, Cellular Core, Finite Element, Thermal Stress

References

[1] J.P.M. Whitty, A. Alderson, P. Myler, B. Kandola, Towards the design of sandwich panel composites with enhanced mechanical and thermal properties by variation of the in-plane Poisson's ratios, Compos. Part A 34 (2003) 525-534.

DOI: 10.1016/s1359-835x(03)00058-7

[2] V.N. Pilipchuk, V.L. Berdichevski, R.A. Ibrahim, Thermo-mechanical coupling in cylindrical bending of sandwich plates, Compos. Struct. 92 (2010) 2632-2640.

DOI: 10.1016/j.compstruct.2010.03.007

[3] T. Kant, S.S. Pendhari, Y.M. Desai, An efficient semi-analytical model for composite and sandwich plates subjected to thermal load, J. Therm. Stresses 31 (2008) 77-103.

DOI: 10.1080/01495730701738264

[4] J.N. Grima, R. Gatt, P.S. Farrugia, On the properties of auxetic meta-tetrachiral structures, Phys. Solid State 245 (2008) 511-520.

DOI: 10.1002/pssb.200777704

[5] F. Meraghni, F. Desrumaux, M.L. Benzeggagh, Mechanical behavior of cellular core for structural sandwich panels, Compos. Part A 30 (1999) 767-779.

DOI: 10.1016/s1359-835x(98)00182-1

[6] T. Liu, Z.C. Deng, T.J. Lu, Structural modeling of sandwich structures with lightweight cellular cores, Acta Mech. Sin. 23 (2007) 545-559.

DOI: 10.1007/s10409-007-0096-z

[7] A. Spadoni, Application of chiral cellular materials for the design of innovative components, Ph.D. Thesis, Georgia Institute of Technology, (2008).

[8] ANSYS Inc., User Manual, Swanson Analysis System, (2009).
