Effect of Wrinkled Microstructure on Surface Wettability of Ginkgo Leaves

Abstract:

In this work, the effect of wrinkled microstructures on surface wettbility of ginkgo leaf was investigated. The upper and lower layers of the ginkgo leaf were comparatively measured by Scanning Electron Microscopy (SEM) for contrast of morphological characters. Measurement results show that the upper epidermis is mainly composed of regularly long-rangle stripes of cellular structures with gently smooth cell wall. On the other hand, the lower one is made up of chaotically isolated cellular structures with wrinkled cell wall. The comparative measurement of contact angle (CA) and roll-off angle in the upper and lower epidermis with deionized water was conducted. Wetting behaviors indicate that the lower has stronger hydrophobicity and weaker adhesion than the upper. Through theoretical analysis, the difference in wettability and adhesion was the result of isolated micro-bumps made by hierarchical wrinkles on the lower epidermis, leading to form solid-air-liquid interface between water and wrinkled surface. This research explains the difference of ginkgo leaf in wettability, and has important reference value in the design and preparation of the surface for the biomimetic materials.

You might also be interested in these eBooks

View Preview

Info:

Periodical:

Key Engineering Materials (Volumes 609-610)

Pages:

1437-1441

DOI:

https://doi.org/10.4028/www.scientific.net/KEM.609-610.1437

Citation:

Cite this paper

Online since:

April 2014

Authors:

Xiao Li Zhao*, Wei Wei An, Zhan Shan Liu, Hai Chao Yu

Keywords:

Contact Angle, Ginkgo Leaf, Roll-Off Angle, Wettability, Wrinkle

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

* - Corresponding Author

References

[1] J. Genzer, J Groenewold, Soft matter with hard skin: From skin wrinkles to templating and material characterization, Soft Matter, Vol. 2 (2006) pp.310-323.

DOI: 10.1039/b516741h

Google Scholar

[2] S. Chen, B. Li, Z. C, Yang, Theoretical methods of bending characteristics analysis of membrane inflatable structures, J. Mech Strength, Vol. 33, No. 3 (2011) pp.403-410.

Google Scholar

[3] A. Schweikart, A. Fery, Controlled wrinkling as a novel method for the fabrication of patterned surfaces, Microchimica Acta, Vol. 165, No. 3-4 (2009) pp.249-263.

DOI: 10.1007/s00604-009-0153-3

Google Scholar

[4] C. M. Chen, S. Yang, Wrinkling instabilities in polymer films and their applications, Polymer International, Vol. 61, No. 7 (2012) p.1041–1047.

DOI: 10.1002/pi.4223

Google Scholar

[5] J. A. Rogers, T. Someya, Y. Huang, Materials and mechanics for stretchable electronics, Science, Vol. 327, No. 5973 ( 2010) pp.1603-1607.

DOI: 10.1126/science.1182383

Google Scholar

[6] J. Y. Chung, A. J. Nolte, C. M. Stafford, Surface wrinkling: A versatile platform for measuring thin-film properties, Advanced Materials, Vol. 23, Issue 3 (2011) p.349–368.

DOI: 10.1002/adma.201001759

Google Scholar

[7] S. Vajpayee, K. Khare, S. Yang, C. Y. Hui and A. Jagota, Adhesion selectivity using rippled surfaces, Adv. Funct. Mater. Vol. 21, No. 3 (2011) pp.547-555.

DOI: 10.1002/adfm.201001652

Google Scholar

[8] C. Bukowsky, J. M. Torres, B. D. Vogt, Slip-stick wetting and large contact angle hysteresis on wrinkled surfaces, J. Colloid Interface Sci, Vol. 354, No. 2 (2011) p.825–831.

DOI: 10.1016/j.jcis.2010.11.034

Google Scholar

[9] T. Ohzono, H. Monobe, K. Shiokawa, et al., Shaping liquid on a micrometre scale using microwrinkles as deformable open channel capillaries, Soft Matter, Vol. 5 (2009) p.46584664.

DOI: 10.1039/b912235d

Google Scholar

[10] W. H. Koo, S. M. Jeong, F. Araoka, K. Ishikawa, S. Nishimura, T. Toyooka and H. Takezoe, Light extraction from organic light-emitting diodes enhanced by spontaneously formed buckles, Nat. Photon, Vol. 4 (2010) pp.222-226.

DOI: 10.1038/nphoton.2010.7

Google Scholar

[11] B. Bhushan, Y. C. Jung, Wetting, adhesion and friction of superhydrophobic and hydrophilic leaves and fabricated micro/nanopatterned surfaces, J. Phys.: Condens. Matter, Vol. 20 (2008) p.225010.

DOI: 10.1088/0953-8984/20/22/225010

Google Scholar

[12] A. G. Franke, I. Heinrich, K. Lieb and A. Fellgiebel, The use of ginkgo biloba in healthy elderly, Age. Vol. 5 (2013) pp.1-10.

DOI: 10.1007/s11357-013-9550-y

Google Scholar

[13] G. Singh, Pharmaceutical benefits of ginkgo biloba: a review, J. Biomed. Pharm. Res. Vol. 2 (2013) pp.15-21.

Google Scholar

[14] G. J. Retallack, Global cooling by grassland soils of the geological past and near future, Annu. Rev. Eeath Planet Sci. Vol. 41 (2013) pp.69-86.

DOI: 10.1146/annurev-earth-050212-124001

Google Scholar
