Improving the Current Stability through the Bubbles-Free Microfluidic Electro-Spray Ionizing Chip

Abstract:

The bubbles in the microfluidic based electro-spray ionizing chips seriously affect the performance of the system. This paper presents a bubble capture method to stabilize the current of the microfluidic based electro-spray ionizing sources. A bubble capture structure was introduced to collect the bubbles. A normal close clamp valve assured a suitable pressure in the bubble capture structure that no liquid in the microfluidic channel can enter; when the bubble capture structure was filled with gas bubbles, the clamp valve was opened to release the bubble and balance the pressure. The results indicated that the current fluctuation, which reflects the stability of the electro-spray ionizing devices, was below 1.8% during the stable cone-jet electro-spray stage (2000V~4500V) for the proposed system, which was a notable improvement comparing with normal microfluidic-based electro-spray ionizing chip without the bubble capture structure.

• Periodical: Key Engineering Materials (Volumes 609-610)
• Pages: 637-641
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.609-610.637
• Online since: April 2014
• Authors: Xiang Qian*, Lang Liu, Quan Yu, Gang Jing, Xiao Hao Wang
• Keywords: Bubbles-Free, Electro-Spray Ionizing, Micro-Fluidics

References

[1] S. Koster, E. Verpoorte, A decade of microfluidic analysis coupled with electrospray mass spectrometry: An overview, Lab on a Chip. 7(2007) 1394-1412.

DOI: 10.1039/b709706a

[2] Gary J. Van Berkel, Feimeng Zhou, Joseph T. Aroson, Changes in bulk solution pH caused by the inherent controlled-current electrolytic process of an electrospray ion source, Int. J. Mass Spectrom. Ion Processes. 162(1997) 55-67.

DOI: 10.1016/s0168-1176(96)04476-x

[3] A. M. Skelley, J. Voldman, An active bubble trap and debubbler for microfluidic systems, Lab on a chip. 8(2008) 1733-1737.

DOI: 10.1039/b807037g

[4] R. Wojcik, O. O. Dada, M. Sadilek, N. J. Dovichi, Simplified capillary electrophoresis nanospray sheath‐flow interface for high efficiency and sensitive peptide analysis, Rapid communications in mass spectrometry: RCM. 24(2004) 2554-2560.

DOI: 10.1002/rcm.4672

[5] Z. Yang, S. Matsumoto, R. Maeda, A prototype of ultrasonic micro-degassing device for portable dialysis system, Sensor Actuat. A-phys. 95(2002) 274-280.

DOI: 10.1016/s0924-4247(01)00741-5

[6] D. D. Meng, J. Kim, C. J. Kim, A degassing plate with hydrophobic bubble capture and distributed venting for microfluidic devices, Journal of Micromechanics and Microengineering. 16(2006) 419-424.

DOI: 10.1088/0960-1317/16/2/028

[7] W. Zheng, Z. Wang, W. Zhang, X. Jiang, A simple PDMS-based microfluidic channel design that removes bubbles for long-term on-chip culture of mammalian cells, Lab on a chip. 10(2010) 2906-2910.

DOI: 10.1039/c005274d

[8] Y. Xia and George M. Whitesides, Soft lithography, Annual review of materials. 28(1998) 153-184.

[9] John B. Fenn, Matthias Mann, Chin Kai Meng, Shek Fu Wong, C. M. Whitehouse, Electrospray ionization–principles and practice, Mass. Spectrom. Rev. 9(1990) 37-70.

DOI: 10.1002/mas.1280090103
