Investigation of the Mechanical Properties of a Stitched Triaxial Fabric

Abstract:

A traxial fabric was investigated for use in composite forming applications. Three stitched layers of fibers, originally oriented at [-60^o/0^o/60^o], comprise the fabric architecture. The mechanical properties of the material are characterized by testing the tensile, shear, and frictional behavior. Conventional shear frame testing methodology assumes that the yarns are originally oriented perpendicular to one another; however, such an assumption is not valid for this particular fabric geometry and must be adjusted. The material behavior is implemented into a discrete mesoscopic finite element model that can predict the response of the material during deformation. Different element types will be investigated to represent the fabric and used to determine the ideal mesh configuration that best captures the fabric behavior. Different modes of deformation will also be studied, and the observed experimental deformation will be compared to the deformation predicted by the finite element model.

• Periodical: Key Engineering Materials (Volumes 611-612)
• Pages: 332-338
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.611-612.332
• Online since: May 2014
• Authors: Cynthia J. Mitchell, James A. Sherwood*, Lisa M. Dangora, Jennifer L. Gorczyca
• Keywords: Composite Material, Finite Element Analysis (FEA), Triaxial Fabric

References

[1] Jauffres, D., Sherwood, J.A., Morris, C.D., and Chen, J.: Discrete mesoscopic modeling for the simulation of woven-fabric reinforcement forming, International Journal fo Forming, Volume 3, Supplement 2, pp.1205-1216, (2009).

DOI: 10.1007/s12289-009-0646-y

[2] Fetfatsidis, K.A., Soteropoulos, D., Petrov, A., Mitchell, C.J., and Sherwood, J.A.: Using Abaqus/Explicit to Link the Manufacturing Process to the Final Part Quality for Continuous Fiber-Reinforced Composite Fabrics. Simulia Community Conference, (2012).

[3] Kong, H., A.P. Mouritz, and R. Paton, Tensile extension properties and deformation mechanisms of multiaxial non-crimp fabrics. Composite Structures, 2004. 66(1–4): pp.249-259.

DOI: 10.1016/j.compstruct.2004.04.046

[4] Sidhu, R. M. J. S., Averill, R. C., Riaz, M. and Pourboghrat, F.: Finite element analysis of textile composite preform stamping, Composite Structures 52, pp.483-497, (2001).

DOI: 10.1016/s0263-8223(01)00038-1

[5] Bathe K. J., Finite Element Procedures. Englewood Cliffs: New Jersey: Prentice Hall, (1996).

[6] Abaqus I. Abaqus Theory Manual Version 6. 6-1: ABAQUS, Inc., (2006).

[7] Lussier, D.: Shear characterization of textile composite formability, MS Thesis, Department of Mechanical Engineering, University of Massachusetts Lowell, (2002).

[8] Cao, J., Akkerman, R., Boisse, P., Chen, J., Cheng, H.S., DeGraaf, E.F., Gorczyca, J., Harrison, P., Hivet, G., Launay, J., Lee, W., Liu, L., Lomov, S., Long, A., Deluycker, E., Morestin, F., Padvoiskis, J., Peng, X.Q., Sherwood, J., Stoilova, T., Tao, X.M., Verpoest, I., Willems, A., Wiggers, J., Yu, T.X., Zhu.: Characterization of mechanical behavior of woven fabrics: experimental methods and benchmark results, Composites: Part A, 39, pp.1037-1053, (2008).

DOI: 10.1016/j.compositesa.2008.02.016
