Increased Productivity in Hot Aluminum Extrusion by Using Extrusion Dies with Inner Cooling Channels Manufactured by Rapid Tooling

Abstract:

The influence of local inner die cooling on the heat balance in hot aluminum extrusion was investigated. For the manufacturing of the die with cooling channels close to the forming zone, the layer-laminated manufacturing method was applied. The new tooling technology was applied in order to decrease the profiles exit temperature and to avoid thermally induced surface defects with the aim to raise the productivity in hot aluminum extrusion processes. Numerical and experimental investigations revealed that, while maintaining the exit temperature of the extrudate, a distinct increase of the production speed up to 300% can be realized, while the extrusion force increases only slightly. An effect on the profiles microstructure was also detected. By applying die cooling, grain coarsening can be significantly limited or even be avoided.

• Periodical: Key Engineering Materials (Volumes 611-612)
• Pages: 981-988
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.611-612.981
• Online since: May 2014
• Authors: Ramona Hölker*, Matthias Haase, Nooman Ben Khalifa, A. Erman Tekkaya
• Keywords: Die Cooling, Hot Aluminum Extrusion, Productivity, Rapid Tooling

References

[1] R. Akeret, Die Produktivität beim Strangpressen von Aluminium-Werkstoffen – Einfluss von Werkstoff & Verfahren, Zeitschrift für Metallkunde, 62 (1971) 6, pp.451-456.

DOI: 10.1515/ijmr-1971-620601

[2] A.K. Das, Special Features of Process Defects in Aluminium Alloy Extrusions, Proceedings of the 4th Int. Extrusion Technology Seminar, 2 (1988), pp.227-233.

[3] M. Bauser, G. Sauer, K. Siegert, Strangpressen, Aluminium-Verlag, Düsseldorf, (2001).

[4] Perfectionnement au filage à chaud des métaux, French Patent, FR 980 (1953), 781.

[5] T.J. Ward, J.F. Heffron, The Effects of Nitrogen and Liquid and Gaseous on Aluminum Extrusion Productivity, Proceedings of the Third International Aluminum Extrusion Technology Seminar, Atlanta, Georgia (1984), pp.211-219.

DOI: 10.1007/bf03339208

[6] H. Yamaguchi, Increase in Extrusion Speed and Effects on Hot Cracks and Metallurgical Structure of Hard Aluminium Extrusions, Proceedings of the Fifth International Aluminum Extrusion Technology Seminar, Chicago (1992), pp.447-453.

[7] R. Hölker, A. Jäger, N. Ben Khalifa, A. E. Tekkaya, Controlling heat balance in hot aluminum extrusion by additive manufactured extrusion dies with conformal cooling channels, International Journal of Precision Engineering and Manufacturing, 14 (2013).

DOI: 10.1007/s12541-013-0200-1

[8] R. Hölker, A. Jäger, A. E. Tekkaya, Rapid Laminated Hot Extrusion Dies with Integrated Cooling Channels, Steel Research International, Special Issue Metal Forming 2012, pp.503-506, (2012).

[9] A. Foydl, A. Segatori, N. Ben Khalifa, L. Donati, A. Brosius, L. Tomesani, A. E. Tekkaya: Grain size evolution simulation in aluminum alloys AA6082 and AA7020 during forward extrusion process, Material Science and Technology, 1 (2013), pp.100-110.

DOI: 10.1179/1743284712y.0000000132

[10] S. Kalz, Numerische Simulation des Strangpressens mithilfe der Methode der finite Elemente, Dr. -Ing. Dissertation, Shaker Verlag, RWTH Aachen, (2002).
