Design of Fruit Picking Device Based on the Automatic Control Technology

Abstract:

£oWith our country's labor cost increase and forestry operations to improve the degree of automation, the automatic picking device will be gradually adopted to pick fruit in the future. This paper discusses the design process of intelligent mobile platform, five axis manipulator, end effector, electrical control device which belong to the automatic fruit picking device. The device is installed in the automatic navigation system and visual identity system, can accurately locate the position and pick fruit. The CAD/CAE software device was mainly used to design and analysis model, and design efficiency, feasibility and scientific were improved. According to the current development trend of fruit species gradually increased, the manipulator hand can adjust, which can pick the different shapes of fruits, and is installed with a visual sensor, pressure sensor, position sensor in the manipulator, and the finger stress analysis was made. In addition, the application of S7-200 model of PLC and pneumatic technology is used in the picking device, so that the overall structure is compact, more stable.

• Periodical: Key Engineering Materials (Volume 620)
• Pages: 471-477
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.620.471
• Online since: August 2014
• Authors: Dong Hui Zhao*, Hui Zhang, Jun Xing Hou
• Keywords: Electrical Control, End Effector, Pneumatic Technology, Robot, Smart Mobile Platforms

References

[1] S.M. Qian: Zhejiang University of Technology, Vol. 12 (2012) No. 3, pp.5-6.

[2] J.T. Xiong and X.J. Zou: Journal of Agricultural Engineering, Vol. 18 (2012) No. 17, pp.56-57.

[3] S.M. Qian, Q.H. Yang, Z.H. Wang, G.J. Bao and L.B. Zhang: Journal of Agricultural Engineering, Vol. 26 (2010) No. 7, pp.105-107.

[4] J.T. Xiong, X.J. Zou, L.J. Chen and A.X. Guo: Journal of Agricultural Machinery, Vol. 22 (2011) No. 9, pp.203-205.

[5] H.F. Wang, B. Li, G.Y. Liu and L.M. Xu: Journal of Agricultural Engineering, Vol. 35 (2012) No. 3, pp.305-308.

[6] B. Li, H.F. Wang, W.Q. Huang and C. Zhang: Journal of Agricultural Engineering, Vol. 23 (2012) No. 3, pp.305-308.

[7] K.L. Zhang, L. Yang, L.J. Wang, L.X. Zhang and T.Z. Zhang: Journal of Agricultural Machinery, Vol. 43 (2012) No. 9, pp.165-167.

[8] R.Y. Shen: Robot Technique, Vol. 15 (2009) No. 9, pp.46-48.

[9] W.L. Huang: Coal Mine Machinery, Vol. 18 (2009) No. 10, pp.20-21.

[10] H.M. Wang: Chinese Hydraulics and Pneumatics, Vol. 29 (2009) No. 11, pp.25-27.

[11] Y.Q. Xu: Journal of Soochow University (Engineering and Technology Edition), Vol. 45 (2009) No. 14, pp.74-75.

[12] C.P. Chen, W. Qin and Z.F. Fang: Chinese Hydraulics and Pneumatics, Vol. 21(2009) No. 10, pp.38-40.

[13] D.H. Zhao: Agricultural Mechanization, Vol. 43 (2010) No. 10, pp.75-77.

[14] D.H. Zhao: Agricultural Mechanization, Vol. 23 (2012) No. 2, pp.101-102.
