Frequency Domain Error Analysis in Ultra-Precision Flycutting

Abstract:

In some special fields such as precision optics, the part surface has strict requirements on the frequency domain errors, besides the conventional spatial domain errors such as surface roughness error. In light of the available works lacking of the frequency domain error analysis in ultra-precision flycutting, this paper therefore presents its frequency domain error analysis. A case study of KDP crystal flycutting is carried out to show its detailed processes, where the processing parameters, tool geometry, motion dynamic error of the machine guideway and tool-work vibration induced dynamic error are considered. A surface profile generation method is put forward. Two cases with different tool-work vibration frequencies are carried out. The spatial frequency spectrum is obtained based on the FFT analysis of the generated profile in the specified direction. After the in-depth analysis, the inherent correlation of the generated spatial frequency components with feed spatial frequency and machine dynamic errors induced spatial frequency under certain machining conditions are found, which is very meaningful for the frequency domain error prediction in the real application. The proposed analysis method can also be applied into other types of surface machining.

• Periodical: Key Engineering Materials (Volume 620)
• Pages: 96-103
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.620.96
• Online since: August 2014
• Authors: Guo Da Chen, Ying Chun Liang, He Ran Wang, Ya Zhou Sun, Jia Xuan Chen
• Keywords: Dynamic Error, Error Analysis, Frequency Domain, Ultra-Precision Flycutting

References

[1] Y. Liang, W. Chen, Y. Sun, G. Chen, T. Wang and Y. Sun: P I Mech Eng B-J Eng, Vol. 226 No. 11 (2012), p.1930-(1936).

[2] G. Chen, Y. Liang, Y. Sun and K. F. Ehmann: Proc 13th euspen Int Conf, Vol. 2 (2013), pp.176-180. ISBN 13: 978-0-9566790-2-4.

[3] C. F. Cheung and W. B. Lee: P I Mech Eng B-J Eng, Vol. 214 No. 6 (2000), pp.463-480.

[4] C. F. Cheung and W. B. Lee: Int J Mach Tool Manu, Vol. 40 No. 7 (2000), pp.979-1002.

[5] H. Wang, S. To, C. Y. Chan, C. F. Cheung and W. B. Lee: Int J Mach Tool Manu, Vol. 50 No. 3 (2010), pp.241-252.

[6] Y. Liang, W. Chen, C. An, X. Luo, G. Chen and Q. Zhang: P I Mech Eng C-J Mec, Published online Dec. 20, 2013, DOI: 10. 1177/0954406213516440.

[7] L. B. Kong, C. F. Cheung and T. C. Kwok: Precis Eng, Vol. 38 No. 2 (2014), p.428–438.

[8] C. An, Y. Zhang, Q. Xu, F. Zhang, J. Zhang, L. Zhang and J. Wang: Int J Mach Tool Manu, Vol. 50 (2010) No. 4, p.374–385.

[9] Y. Liang, W. Chen, Q. Bai, Y. Sun, G. Chen, Q. Zhang and Y. Sun: Int J Adv Manuf Tech, Vol. 69 No. 1-4 (2013), p.237–244.

[10] G. Chen, Y. Liang, K. F. Ehmann, Y. Sun and Q. Bai: Proc SPIE (2014), to appear.

[11] G. Chen, Y. Liang and Y. Sun: Int J Adv Manuf  Tech (2014), to appear.
