Simulative Model for the Evaluation of Thermo-Mechanical Effects in Friction Stir Spot Welding (FSSW) of Aluminum Sheets

Abstract:

A study was performed to evaluate how the Friction Stir Spot Welding process parameters affect both the thermal distribution in the welding region and the welding forces. An experimental campaign was performed by means of a CNC machine tool and FSSW lap joints on AA6060-T6 aluminum alloy plates having a thickness of 2+2 mm were executed. Five thermocouples were inserted into the samples at a specific distance from the specimen center. A set of tests was carried out by varying the process parameters, namely rotational speed, axial feed rate, plunging depth and dwell time. Axial welding forces were also measured during the execution of the experiments by means of a piezoelectric load cell. The experimental data collected were used to set up and to validate a simulative model of the process. In particular, a 2D FEM model was set up using the commercial code Deform 2D. A 2-dimensional FEM code was preferred in order to guarantee a very simple and practical model able to achieve results in a very short time. Since it is not possible to simulate the rotation of the tool in a 2D configuration, a specific external routine for the calculation of the developed thermal energy due to the friction between tool and workpiece was set up and implemented into the code starting from the local pressure distribution along the contact area.

• Periodical: Key Engineering Materials (Volumes 622-623)
• Pages: 557-566
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.622-623.557
• Online since: September 2014
• Authors: G. D’Urso*, Claudio Giardini
• Keywords: Aluminum (Al), FEM Simulation, FSSW, Process Parameter, Temperature Distribution
