Research on Wrinkling Behavior in Tube Hydroforming with Axial Feeding

Abstract:

Tube hydroforming (THF) is one of metal forming technologies which has been widely used to manufacture complex hollow workpeices. In THF, a variety of failures may occur and one of them is wrinkling. But recent researches show that wrinkling may be used as a preforming process to improve the formability of tubes. In this paper, a new geometry-based wrinkling indicator is proposed to evaluate the wrinkling level in THF and the wrinkle evolution diagram (WED) based on the shape change of the wrinkles is presented to display the four-stage evolution of the useful wrinkles. The wrinkling levels in THF with axial feeding under various loading paths are predicted respectively via finite element simulation, the influence of loading paths on the wrinkling behavior is investigated, and the evolving stages of the useful wrinkles is revealed via the proposed WED. The results indicate that the proposed wrinkle indicator can distinctly evaluate the wrinkling level, the wrinkling level under pulsating loading path is higher than that under polygonal linear one and four-stage evolution of the useful wrinkles could be evidently demonstrated via the WED. Notation

• Periodical: Key Engineering Materials (Volumes 622-623)
• Pages: 739-746
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.622-623.739
• Online since: September 2014
• Authors: Zhu Lin Hu*, Lian Fa Yang, Yu Lin He
• Keywords: Axial Feeding, Formability, Tube Hydroforming, Wrinkling Behavior

References

[1] Byeongdon Joo, Sangyun Kim, Suhee Kim, YoungHoon Moon, FMEA for the reliability of hydroformed flanged part for automotive application, J. Mech. Sci. Technol. 27 (2013) 63-67.

DOI: 10.1007/s12206-012-1226-5

[2] P. Ray, B.J. Mac Donald, Determination of the optimal load path for tube hydroforming processes using a fuzzy load control algorithm and finite element analysis, Finite. Elem. Anal. Des. 41 (2004) 173-192.

DOI: 10.1016/j.finel.2004.03.005

[3] WANG Xiaosong, YUAN Shijian, WANG Zhongren, RESEARCH ON WRINKLING BEHAVIOR IN TUBE HYDROFORMING, Acta. Metall. Sin. 39 (2003) 1276-1280. (In Chinese).

[4] M. Loh-Mousavi, M. Bakhshi, K. Mori, T. Maeno, M. Farzin, S.J. Hosseinipour, 3-D Finite Element Simulation of Pulsating Free Bulge Hydroforming of Tubes, Iran. J. Sci. Technol. B. Technol. 32 (2008) 611-618.

DOI: 10.4028/www.scientific.net/kem.340-341.353

[5] L.C. Zhang, T.X. Yu, R. Wang, Investigation of sheet metal forming by bending—Part I. Axisymmetric elastic-plastic bending of circular sheets pressed by cylindrical punches, Int. J. Mech. Sci. 31 (1989) 285-300.

DOI: 10.1016/0020-7403(89)90004-0

[6] M. Strano, S. Jirathearanat, T. Altan, Adaptive FEM simulation for tube hydroforming: a geometry-based approach for wrinkle detection, Ann. CIRP. 50 (2001) 185-190.

DOI: 10.1016/s0007-8506(07)62101-5

[7] Xiaofeng Liu, Lianfa Yang, Yuxian Zhang, Wrinkling Identification and Wrinkle Distribution of a Tube in Hydroforming with Radial Crushing, J. Mater. Process. Technol. 291-294 (2011) 662-667.

DOI: 10.4028/www.scientific.net/amr.291-294.662

[8] Mikkelsen L. P., Elastic-viscoplastic buckling of circular cylindrical shells under axial compression, Eur. J. Mech. A-Solid. 14 (1995) 901-920.

[9] F.C. Bardi, S. Kyriakides, Plastic buckling of circular tubes under axial compression — part I: Experiments, Int. J. Mech. Sci. 48 (2006) 830-841.

DOI: 10.1016/j.ijmecsci.2006.03.005

[10] Zhang Tie, The Significance and Measure of the Flatness of Plate, Light Alloy Fabrication Technology, 25 (1997) 10-12. (In Chinese).

[11] K. Mori, T. Maeno, S. Maki, Mechanism of improvement of formability in pulsating hydroforming of tubes, Int. J. Mach. Tool. Manu. 47 (2007) 978-984.

DOI: 10.1016/j.ijmachtools.2006.07.006

[12] HAN Cong, ZHANG Weiwei, XIE Wencai, YUAN Shijian, Analysis of wrinkling behavior of hydroformed torsion beam, J. Harbin Inst. Technol. 45 (2013) 85-88. (In Chinese).
