Automatic Optical Measurement of High Density Fiber Connector

Abstract:

This paper will develop an automatic and fast optical measurement system for high density optical fiber connector measurement, which base on the optical project method. It will meet the lot of optical fiber connector measurement need. This system includes a high intensity and high collimated LED source, a high accuracy and high stiffness linear stage, 2 multi-degree-of-freedom adjustment mechanisms and a high resolution coaxial telecentric imaging system and image processing software. The system of measurement results and commercial measuring instruments comparing the results of its error is less than 0.6μm. To measure a V groove needs 750ms, this result may satisfy the requirements of automatic inspection.

You might also be interested in these eBooks

Precision Engineering and Nanotechnology V

View Preview

Info:

Periodical:

Key Engineering Materials (Volume 625)

Pages:

305-309

DOI:

https://doi.org/10.4028/www.scientific.net/KEM.625.305

Citation:

Cite this paper

Online since:

August 2014

Authors:

Chun Li Chang*, Chun Jen Chen, Wen Hong Wu

Keywords:

AOI, Collimated Light, Fiber Connector, Subpixel, V Groove

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

* - Corresponding Author

References

[1] Information on http: /yagishitagiken. jp/original8. html#hikari.

Google Scholar

[2] K. Jensen; D. Anastassiou, Subpixel edge localization and the interpolation of still images, , Image Processing, IEEE Transactions on Vol. 4, no. 3, pp.285-295. (1995).

DOI: 10.1109/83.366477

Google Scholar

[3] E.P. Lyvers, O.R. Mitchell, M.L. Akey, A.P. Reeves, Subpixel measurements using a moment-based edge operator, Pattern Analysis and Machine Intelligence, IEEE Transactions on Vol. 11, no. 12, pp.1293-1309. (1989).

DOI: 10.1109/34.41367

Google Scholar

[4] J. Räsänen, K.E. Peiponen, On-Line Measurement of the Thickness and Optical Quality of Float Glass with a Sensor Based on a Diffractive Element, Applied Optics, Vol. 40, Issue 28, pp.5034-5039. (2001).

DOI: 10.1364/ao.40.005034

Google Scholar

[5] C.S. Lin, J. Cho, Y.L. Lay, C.H. Lin, N. Lin, The auto-measurement of the gap of LCD glass plates using sub-pixel accuracy estimation, Vol. 117, Issue 8, pp.349-354. (2006).

DOI: 10.1016/j.ijleo.2005.11.006

Google Scholar

[6] P. Rockett , The Accuracy of Sub-Pixel Localisation in the Canny Edge Detector, In Proc. of the British Machine Vision Conference (BMVC), pp.392-401. (1999).

DOI: 10.5244/c.13.39

Google Scholar
