A New Method of Reducing the Measurement Blind Area for MPS

Abstract:

The magnetostrictive position sensor (MPS), which can be used to detect the absolute position of motion objects in a coordinate system, is widely used in industry. It is especially applicable to the conditions of greasy dirt, oil and water. As an important disadvantage for MPS, the measurement blind area (BA) occurs due to the induced electromotive force (EMF) oscillation when the magnetic field of excitation pulse passes the receiving coil. A new structure with two coils is proposed in this paper. Two signals can be obtained by each coil, respectively, and the BA will be improved by different operations between two signals. Finally, the validity of this approach has been proved by experiments.

You might also be interested in these eBooks

Precision Engineering and Nanotechnology V

View Preview

Info:

Periodical:

Key Engineering Materials (Volume 625)

Pages:

9-13

DOI:

https://doi.org/10.4028/www.scientific.net/KEM.625.9

Citation:

Cite this paper

Online since:

August 2014

Authors:

Chao Deng*, Yi Hua Kang, Qian Zhou, Hui Li

Keywords:

Magnetostrictive Position Sensor, Measurement Blind Area, Torsion Strain Wave, Waveguide Signal

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

* - Corresponding Author

References

[1] Fernando Seco, José M, Antonio R J, Improving the Accuracy of Magnetostrictive Linear Position Sensors, IEEE Transactions on Instrumentation and Measurement, Vol. 58, No. 3, March (2009).

DOI: 10.1109/tim.2008.2005260

Google Scholar

[2] Wakiwaka, H. Displacement Sensor Using Magnetostrictive Wire and Decrease of its Hysteresis Error. Sensors 2008, 21, 379-384.

DOI: 10.1007/978-3-540-69033-7_18

Google Scholar

[3] Hristoforou, E.; Niarchos, D. A coily Magnetostrictive Delay Line Arrangement for Sensing Applications. Sensors and Actuators A 91 (2001) 91-94.

DOI: 10.1016/s0924-4247(01)00515-5

Google Scholar

[4] Fernando Seco, J. M. Mart'n, Hysteresis Compensation in a Magnetostrictive Linear Position Sensor. Sensors & Actuators A, 110 (2004), 247-253.

DOI: 10.1016/j.sna.2003.09.031

Google Scholar

[5] David S. Nyce, Magnetostrictive position transducer with band passed mode converter output for rejecting mechanical noise, Patent Number: 5, 367, 255, November. (1994).

Google Scholar

[6] C Favieres, V Madurga, Studies of the Magnetoelastic inverse Wiedemann Effect in Pulsed Laser Deposited Cylindrical Cobalt films. J. Phys.: Condens. Matter 16 (2004) 4725–4741.

DOI: 10.1088/0953-8984/16/26/007

Google Scholar
