Transport of Water and Chloride Ion in Cement Composites Modified with Graphene Nanoplatelet

Abstract:

Cement composites are vulnerable to harsh environments in which the chloride ions can ingress into concrete and thus cause corrosion of steel. In this study, the barrier effect of adding 2-D nanoparticles on the transport properties of cement-based materials was investigated. Graphene nanoplatelet (GNP), which comprises of a few layers of graphene stacked together, is chosen as a candidate in this study due to its impermeability and also its electrical conductivity which can be exploited for self-sensing functionality. Due to the large aspect ratio of the GNP, it is expected that the dispersion of these 2-D nanobarriers can contribute to the reduced permeability and diffusion of harmful agents. Experiments were carried out on cement mortar with 0%, 2.5%, 5.0% and 7.5% of GNP by weight of cement. The water penetration depth, chloride diffusion coefficient and chloride migration coefficient were reduced by 64%, 70% and 31% respectively with the addition of as little as 2.5% of GNP. This reduction can be attributed to the barrier effect of GNP which increases the tortuosity against water and chloride ions penetration, and also the refinement of the capillary pores which was revealed from the MIP tests. At GNP content exceeding 5%, the nanoparticles agglomerate, causing weak pockets which compromises the benefits of adding GNP to impede the ingress of fluids.

• Periodical: Key Engineering Materials (Volumes 629-630)
• Pages: 162-167
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.629-630.162
• Online since: October 2014
• Authors: Hong Jian Du*, Sze Dai Pang
• Keywords: Barrier Effect, Diffusivity, Durability, Nanoparticle, Permeability, Sorptivity

References

[1] T. Ji, Preliminary study on the water permeability and microstructure of concrete incorporating nano-SiO2, Cem. Concr. Res. 35 (2005) 1943-(1947).

DOI: 10.1016/j.cemconres.2005.07.004

[2] M.H. Zhang, H. Li, Pore structure and chloride permeability of concrete containing nano-particles for pavement, Constr. Build. Mater. 25 (2011) 608-616.

DOI: 10.1016/j.conbuildmat.2010.07.032

[3] D. Kong, X. Du, S. Wei, H. Zhang, Y. Yang, S.P. Shah, Influence of nano-silica agglomeration on microstructure and properties of the hardened cement-based materials, Constr. Build. Mater. 37 (2012) 707-715.

DOI: 10.1016/j.conbuildmat.2012.08.006

[4] H. Du, H.J. Gao, S.D. Pang, Use of 2-D nano-particles to enhance the concrete resistance to chloride ingress, XIII International Conference on Durability of Building Materials and Components, September 2-5, 2014, Sao Paulo, Brazil.

[5] L.E. Nielsen, J. Models for the permeability of filled polymer systems, Macromolecular Sci.: Part A – Chemistry, 1 (1967) 929-942.

DOI: 10.1080/10601326708053745

[6] R.K. Bharadwaj, Modelling the barrier properties of polymer-layered silicate nanocomposites, Macromolecules. 34 (2011) 9189-9192.

DOI: 10.1021/ma010780b
